Front View of Access Point
Name
Description
Steady Blue
The device is powered up.
1
LED
(Power)
Off
No power is supplied to the device.
2
LED
(Diagnostic)
Flashing Green
This indicates the flash during the
power-up. The LED will goes off
when the diagnostic is passed.
Steady Green
WAN connection is established.
3
LED
(WAN Link/Act)
Flashing Green
Data
transmission
at
WAN
connection.
3 4 5
1
2
