Front Panel Operation
FRONT PANEL CONTROLS
■ Power ON/OFF - Press ON/STANDBY button
(1) to turn the unit on/off.
■ Loading a Disc - Press OPEN/CLOSE button
(7) and set the disc (label side up) onto the
disc tray (4). Push the disc tray gently and
it will close; the unit will begin playback.
■ Ejecting a Disc - Press OPEN/CLOSE button
(7) and the disc tray will slide out. Then
remove the disc and close the disc tray.
■ Stop Playback - Press STOP button (6), and
playback will cease.
■ Resume Playback - Press PLAY button (6),
and playback will resume.
■ Audio/Video Inputs - The AUDIO (3) and
VIDEO (2) inputs allow alternate audio
and video sources to play through the DVD
player.
■ Menu - Press MENU button (6) to display
the root menu. Press continuously to
advance through the selections. Once the
desired selection is highlighted, press
PLAY button (6) to select.
FRONT PANEL FEATURES
1 On/Standby Button Turns the unit on and off.
2 Video Input Plug in alternate video input here.
3 Audio Input Plug in alternate audio input here.
4 Display Panel Displays playback information.
5 Disc Tray Place the disk here.
6 Play/Stop/Pause/Menu Button Plays, stops or pauses playback, and menu selection.
7 Open/Close Button Opens and closes the disc tray.
2 7 6 5 4 1 3
