Dimensions (W x H x D):
BX-300
19"
X
3/2" X
10-9/16" (482m/m
x
88m/m
x
268m/m)
BX-600
19"
X
5-4/16"
X
10-9/16" (482m/m
x
132m/m
x
268m/m)
BX-1200 19"
X
5-4/16"
X
10-9/16" (482m/m
x
132m/m
x
268m/m)
Weight:
BX-300
17.8tbs (8.1 kg)
BX-1200
31.9lbs (14.5 kg)
BX-600
25.5lbs(11.6 kg)
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
(^ N AM ES/FUNCTIQNS)
BX-300:
1} Power Switch
2) Power Indicator (LED)
3) Overload Indicator (LED)
4) MIC-1 Input Phone Jack
5) Bass Tone Control
6) Treble Tone Control
7) AUX/PHONO Select Switch
8) Peak Indicator (LED)
9) MiC-1 Volume Control
10) iVllC-2 Volume Control
11) M1C-3/PHONE Volume Control
12) AUX/PHONO Volume Control
13) MASTER Volume Control
14) GROUND Terminal
15) MlC-3 Input Terminals
16) MlC-2 Input Terminals
17) AUTO/MANUAL Muting Control Select Switch
18) Muting Level Control
19) Low impedance Output Terminals
20) AC Fuse (2A)
21) AC Outlet (Max. 100W, unswitched)
22) AC Power Supply Cord
23) PHONO Input Jacks
24) AUX Input Jacks
25) MIC-3/PHONE Select Switch
26) PHONE Input Terminals
27) Manual Muting Control Terminals
28) Constant Voltage Output Terminals (25, 70,7V)
29) Line Output Jack
30) DC 13,2V Power input Terminals
10
1 1
1 2
13
23 24 25 26
27
28
29
30
@ ' «$
e*
14
1
1
r~pMaaiaMM j ^
;0:-
15
16 17 18
I
