□ Valet mode. Make sure the remote car starter is able to properly enter and exit valet mode. When setting the
remote car starter into valet mode, pressing the lock button will lock the doors without activating the starter kill.
(Refer to the user guide for further information on valet mode.)
□ Idle mode. Make sure the vehicle properly enters and exits idle mode.
□ Most comebacks are the result of misunderstandings about how a product works or performs. Take the
time to properly explain all functions and features to the customers before they leave the premises.
Doing this will save time and money.
Diagnostics - Parking Light Flash Table
Flashes Description
1
• Doors locked, starter kill armed.
• Run time has expired.
• TRUNK button pressed.
• Start signal received by the module.
• Cold weather mode cancelled.
2
• Doors unlocked, starter kill disarmed.
• Remote start attempt cancelled by remote.
• Exiting ignition valet.
• Exiting remote valet.
• Power-up reset.
• Board set from manual to automatic; power
ON.
• Power ON to OFF ( automatic transmission).
2 slow flashes then
8 quick flashes
♦ Reset from Manual to Automatic
3
• Entering cold weather mode.
• Extended run time.
• Entering or exiting Ready Mode
• Entering ignition valet.
• Entering remote valet.
• Disabling LED
3 Slow
(automatic transm.)
♦ Parking brake is engaged ♦ Yellow loop has been reconnected
4
• +12 V detected on the brake input wire either while cranking or during run time.
• Entering multi-speed tach programming.
• Entering time delay adjustment in virtual tach system
• Board set from automatic to manual; power ON.
• Power ON to OFF ( manual transmission).
5 Fast
• Tach signal programmed
• New transmitter programmed
6 • A remote start was attempted while a tach-before-crank signal was detected before cranking.
8 • Unit reset: see “Resetting the Module” (p. 6)
10 • A ground (-) signal was detected on the hood pin input wire.
1 - pause - 2
♦ There was a remote start attempt while the vehicle was in valet mode.
• Failed start: vehicle’s low battery voltage.
ON SOLID for 3
seconds>.
^followed by 1 flash Exiting cold weather mode
^followed by 3 flashes Entering cold weather mode
ON continuously • Idle mode: Idle mode is engaged
• Run time: The vehicle has been remote started and is in run time.
ON 2 seconds
• The hood has been opened and a ground (-) signal has been detected on the hood pin input
wire.
ON 4 seconds • Locking or unlocking a door (with Door pulses configured to 4 sec.)
ON 20 seconds ♦ The hood pin has been flashed and you are now in the programming centre.
Continuous flashes
25 seconds
♦ Panic mode is activated.
Continuous flashes
60 seconds
♦ OEM alarm triggered (Honk)
A complete version of this guide can be downloaded from the following sites: www.autostart.ca.
www.directed.com and www.directechs.com.
http://www.autostart.ca Installation Guide
T W O - W A Y 6 - B U T T O N L C D
A U T O M A T I C / M A N U A L T R A N S M I S S I O N R E M O T E S T A R T E R
W I T H V I R T U A L T A C H S Y S T E M
( A S P R G - 1 0 0 0 C O M P A T I B L E )
A S - 3 4 7 2 T W - F M
Quick Installation Guide
Table of Contents
Entering Programming Mode................................................................ 1
Manual or Automatic Transmission...................................................... 1
Transmitter Programming Procedure.................................................... 2
Entering Programming Options............................................................. 2
Programming Options............................................................................ 2
Virtual Tach System............................................................................... 6
Optional Time Delay Adjustment In Virtual
Tach System.............................................................6
Entering Programming Mode
Tach Programming.................................................................................6
Horn Honk Timing.................................................................................. 6
Resetting the Module............................................................................. 6
Supplementary Information....................................................................6
Fifth Relay Output (2nd IGN, ACC or CRANK).........6
Tach jumper settings................................................7
Testing.................................................................................................... 7
Diagnostics - Parking Light Flash Table................................................8
Using the Hood Pin
Using the Antenna Programming Assistance Button
(A.P.A.B.)
• Press and hold the hood pin for 4 seconds. • Make sure that the hood is closed.
♦ Release the hood pin.
The parking lights will turn ON.
♦ Turn the ignition key to the IGNITION ON (RUN) position.
♦ While the parking lights are ON, press the hood pin once
more and release immediately.
The parking lights will turn ON and stay ON for 20
seconds.
• Within 5 seconds, press the programming button on the
antenna twice for 1 second each time.
The LED will come ON solid.
* You now have 20 seconds to select one of the sub­
menus.
* You now have 20 seconds to select one of the sub­
menus.
Note: To exit programming mode, close the hood.
Note: To exit programming mode, press on the antenna
button once (the LED will come ON) and release.
Manual or Automatic Transmission
This module may be installed on vehicles with manual or automatic transmissions. It is originally configured for manual
transmissions. If the vehicle you are working on is automatic, it is mandatory to make a few quick and easy modifications before
the unit is connected. In the event that the configuration requires changes afterwards, a complete reset will be
necessary before those changes become effective.
To install this unit in a vehicle with a manual transmission:
Make sure the Yellow loop on the PC board is connected.
Connect the Black/White handbrake wire located on the 12-pin harness to the vehicle handbrake switch.
Connect the Violet (+) door input OR the Green (-) door input wire located on the 12-pin harness to the vehicle
door pin wire, which monitors all the doors of the vehicle (only use 1 of the 2 door trigger inputs).
Make sure the Violet/White TACH wire is plugged in - the T a CH wire MUST be hooked up when the module is
set for a manual transmission.
Make all your regular connections.
Power up the unit by first inserting the 5-pin connector, then the 6-pin connector and finally the 12-pin connector.
The parking lights will flash 4 times to confirm that the unit is in manual mode.
When learning the transmitter, the parking lights will flash 5 times quickly, confirming that the module is set to
manual mode.
Upon the first successful remote start, the system will lock the transmission settings to manual mode.
Notice
The manufacturer will accept no responsibility for any electrical damage resulting from improper installation of the product, be that either
damage to the vehicle itself or to the unit. This unit must be installed by a certified technician using all safety devices supplied. Please
note that this guide has been written for properly trained Autostart technicians: a certain level of skills and knowledge is therefore
assumed. Please review the installation guide carefully before beginning any work.
Warning
Before installing the unit, if installing on a vehicle with a manual transmission, test that the OEM Door Switch contacts of the vehicle work
well, and that the Parking Brake system operates properly. If installing on a vehicle with an automatic transmission, test that the vehicle
does not start when the gearshift lever is in the “Drive” position. If it starts in gear, reset the remote starter to manual transmission.
