Block Diagram: Matrices 3 and 4 can be separated from matrices 1 and 2 via the
loop thru switches, providing even more flexibility.
S P E C I F I C A T I O N S
Frequency Response ±.3dBm 20 to 20KHz C.M.R. of Inputs >75dBm @ 60Hz
Input Impedance IM.O balanced LED Clip Threshold +19dBm unbalanced
Max. Input Level +22dBm unbalanced
+25dBm balanced
+28dBm balanced Range of Level Pots -60 to -t 13 dBm
Output Impedance lOOO balanced Range of Headphone
Max. Output Level +22dBm unbalanced
Volume Control -60 to H-13dBm
+28dBm balanced Power Consumption .3 Amps Max. A.C. @120VAC
Total Gain 26dB
.3 Amps Max. A.C. @230VAC
T.H.D.+n .007% at IkHz
<.02% 20Hz-20kHz
AC Dropout Voltage -tlOS V.A.C. @120Vac
4-205 V.A.C. @230Vac
Rise Time 8pS
Internal Mains Fuse .25 Amps Slo Bio 3AG
Phase Shift <.01 degree at IkHz
Size (Single Space Standard E.I.A. Spec )
19.0''(482.6mm) Width
Intermodulation Distortion .01% at unity gain 6.0"( 152.4mm) Depth
E.I.N. -90dBm
3.5"(88.9mm) Height
Working S/N Ratio (22dB headroom)
Shipping Weight 11 lbs (4.99kg)
at unity gain -85dBm Unit Weight 9.0 lbs (4.08kg)
at 18 dB gain -79dBm
