10. Connect tubing to equipment. Open all water supply valves and check for leaks.

11. If no leaks turn on equipment and check for normal operation.

Installation Drawings & Dimensions

. 1/2" MPT ADAPTER

REQ'O TO ADAPT TO
EPT (MEU

' PIPE OR

1/2" ID FLEXIBLE

REINFORCED BEVERAGE

TUBING FROM

V CHLORINATED MUNICIPAL

\ WATER SUPPLY

WATER
SUPPLY

INSTALL - MIN -

1/2" FULL FLOW
BALL VALVE

w/ 1/2" FPT
INLET CONNECTION

(VALVE NOT INCL'O)

1/2" MPT

ADAPTER

REQ'D TO
ADAPT TO
FPT OUTLET

PROVIDE APPROPPRIATE

PIPE/TUBING TO EQUIPMENT
FOR FILTERED WATER,

II I

NOTE;
DO NOT MOUNT FILTER
ASSEMBLY BEHIND ICE
MACHINE OR OTHER
APPLIANCES THAT WOULD
IMPEDE ACCESS FOR
MAINTENANCE OF
FILTRATION SYSTEM

6 9/16"

4 1/2"

1". 2 1/2"

1/2"

FULL

FLOW

BALL

VALVE w/ 1/2" FPT

inlet

connection

FROM BUILDING WATER
SUPPLY.

MOUNT TO SECURE
WALL ON STUDS OR
WALL PANEL.
DO NOT MOUNT TO
UNSUPPORTED SHEET
ROCK OR GYPSUM
BOARD

1/2" FPT OUTLET
CONNECTION TO
EOUIPMENT
