PARTS LIST FOR UTILITY CART MODEL NO. 45-02171
REF.
NO.
PART NO.
QTY.
DESCRIPTION
1
23984
2
Cart Body
3
23504
1
Tailgate
4
62457
1
Sub-Ass'y - Rear Angie
5
23549
2
Guide, Tailgate — Inside
6
23548
2
Guide, Tailgate — Outside
7
23490
1
Front Panel
8
23821
1
Wheel Support
9
23363
1
Latch Stand Bracket
10
62455
1
Ass'y. Latch Lock
11
23014
1
Hitch Bracket
12
23989
1
Draw Bar Tongue
13
23820
1
Wheel Axle 1'' Dia.
14
23484
2
Cap, Front Corner
15
62359
2
Wheel Axle Bracket
16
43649
2
Wheel, 20 x 10-8
17
43093
2
Cotter Pin 1/8” Dia. x 1-1/2” Lg.
18
43601
4
Washer, Flat 1.032” I.D.
19
43014
2
Hub Cap
20
43175
25
Hex Bolt 1/4”
X
1/2” Lg.
21
43866
6
Hex Bolt 1/4”
X
5/8” Lg.
22
43012
6
Hex Bolt 1/4”
X
3/4” Lg.
23
1 509-69
2
Hex Bolt 1/4”
X
1-3/4” Lg.
24
43177
39
Lock Washer 1/4” I.D.
25
43178
39
Hex Nut 1/4” Thread
26
43182
8
Hex Bolt 5/6-3/4” Lg.
27
43064
8
Lock Nut 5/6” Thread
28
43814
14
Slotted Truss Head Bolt 5/16” x 3/4” Lg.
29
43086
14
Lock Washer 5/16” I.D.
30
43083
14
Hex Nut 5/16” Thread
31
43001
2
Lock Washer 3/8” x 1” I.D.
32
43003
2
Lock Washer 3/8” I.D.
33
43015
2
Hex Nut 3/8” Thread
34
44678
2
Tube Spacer
46085
1
Owner's Manual
