GENERAL SAFETY PRECAUTIONS
Preventing accidents is the responsibility of every
equipment operator. The following general safety
precautions must be fully understood and followed
by every operator.
1. Do not at anytime carry passengers in this cart.
It is designed for carrying materials only and not
intended to carry passengers.
2. Do not tow this utility cart on a public
thoroughfare at any time. The operator is risk­
ing injury from passing vehicles. Most local
ordinances
prohibit operating a cart and
tractor such as this on a public thoroughfare.
3. When towing cart do not drive too close to a
creek or ditch and be alert for holes and other
hazards. The above could cause you to lose
control of the cart and tractor.
4. Be careful on any grade (hill) and stay off of
steep grades.
5. Maximum towing speed - 10 M.P.H.
OPERATION
To dump rr erial from the trailer box, remove the
tailgate by lifting it straight up and out from between
the guides. Release the spring latch by pulling the
latch handle forward, away from the trailer box.
▲
CAUTION
To avoid possible injury, be sure that
no one is near the trailer before
releasing latch.
A cord may be attached to the spring latch handle
for easy release by the operator while in the tractor's
seat. The trailer box will tilt backward to empty its
contents. After unloading, pull the front of the box
down toward the trailer tongue until the latch snaps
in place. Replace tailgate if desired.
NOTE
For best handling, do not load trailer
too heavily behind center of axle.
NOTE
Weight limit-One cubic foot of dirt weights
approximately 150 lbs.
Do Not exceed cart weight capacity.
SPECIFICATIONS; MODEL 45-0217 -
(Super 17)
Bed:
17.0 Cu. Ft.
16 Ga. Steel Construction
36-1/2" W; 61" L; 14" H;
Approx. Inside Dim. —34" x
5 8 - 1 / 2 "
Tailgate: Removable with Reinforced
Guides
Tires: 20.0" x 10.0" Pneumatic, Turf
Tread
Axle: 1.0" Dia. Steel
Capacity: Up to 1700 Lbs. Max.
Finish: Baked Enamel —Body; Ivory;
Black
Approx. Sh. Wt.: 195 Lbs.
Carton Size: 16-1/2" Hx20-1/2" W x 60-1/2"
(11.55 Cu. Ft.)
Carton Size: 20-1/2" H x 20-1/2" W x
20-1/2" L (4.99 Cu. Ft.)
MAINTENANCE
At the beginning of each season, lubricate the latch,
latch pivot bolt, and the axle where the hitch tongue
pivots, with a light machine oil.
1. Grease or oil wheel bearings occasionally. Use
automotive wheel bearing type grease or 20
weight oil.
2. Recommended tire pressure is 12-14 Lbs.
