CRESTRON GREEN LIGHT™ Architectural Dimming
Appendix B: Module Specifications
Specifications for the GLXP modules are listed in the following table.
GLXP Module Specifications
SPECIFICATION GLX-DIM6 GLX-HSW8 GLX-DIMFLV8
Description 6 Channel Dimming/Switching
Module
8 Channel High-Inrush Switch
Module
8 Channel 0-10V Fluorescent
Dimmer Module
Number of Outputs 6 8 8
Cresnet Power
Usage*
5 Watts 5 Watts 5 Watts
Input Voltage 100 – 277 VAC 50/60 Hz 100 – 277 VAC 50/60 Hz 100 – 277 VAC 50/60 Hz
Supported Load
Types Incandescent, magnetic low
voltage (MLV), electronic low
voltage (ELV), neon/cold
cathode, fluorescent ballast Incandescent, magnetic low
voltage (MLV), electronic low
voltage (ELV), neon/cold
cathode, fluorescent ballast,
HID, motor Dimmable Loads:
0-10 VDC dimmable
fluorescent ballasts (i.e.
Advance Mark 7 or other
ballasts that comply with the
specifications for control by DC
voltage in ANSI C82.11:2002
and IEC60929:2006)
Non-Dim Loads:
Incandescent, HID, magnetic
low voltage (MLV), electronic
low voltage (ELV), neon/cold
cathode, and fluorescent
ballasts, motor
Maximum Load
Lighting
Motor
16 A per output
N/A
16 A per output
½ HP @ 120V
1 HP @ 230V,
1 HP @ 277V
16 A per output
½ HP @ 120V
1 HP @ 230V,
1 HP @ 277V
Environmental
Temperature
Humidity
Heat Dissipation
32º to 104º F
(0º to 40º C)
10% to 90% RH
(non-condensing)
10 BTU/Hr
32º to 104º F
(0º to 40º C)
10% to 90% RH
(non-condensing)
10 BTU/Hr
32º to 104º F
(0º to 40º C)
10% to 90% RH
(non-condensing)
10 BTU/Hr
* Power usage will be zero whenever AC power is present on circuit 1 on the module. Use of Cresnet power is optional.
Installation Guide – DOC. 6688A CRESTRON GREEN LIGHT Architectural Dimming
• 15
