PARTS AND FEATURES
r
LID
Be sure to keep the !id
closed during washing
and spinning.
DETERGENT BOX
FABRIC SOFTENER
DISPENSER
BLEACH INLET
MAGIC FILTER
Unt will be collected in the
filter during washing
FRONT CONTROL
PANEL
ADJUSTABLE LEGS
Adjust the length of the legs
when installing the washer.
WATER SUPPLY
HOSE{HOT)
WATER SUPPLY
HOSE(COLD)
DRAIN-HOSE
(PUMP)
SPIN BASKET
Stainless
“BOOMERANG”
PULSATOR
POWER CORD
SOUND ABSORPTION
PANEL
GROUND LEAD
When the water pipe is metal,
make sure to cover the end
of the ground wire.
WATER DRAIN HOSE
(option)
