Parts Breakdown
Locauon No.
Code No.
Description
Specification
Q'ty
Remarks
1
DC96 - 00038B
ASSY - POWER CORD
EP3
1
2
DC60-10003C
SCREW - MACHINE
M4
X
8 BS
1
3
DC60-20060A
SCREW-TAPPING
2
4
DC61 -10226A
COVER-BACK
PP
1
5
DC97 - 00121C
ASS'Y-DAMPER
FRONT/RED
2
DC97-00121B
ASS'Y - DAMPER
REAR/WHITE
2
6
DC91 -11919B
ASSY - FRAME
SBHG1- A
1
PUMP
7
6046 - 000310
STAND - OFF
7
8
DC90-11110C
ASS'Y - PUMP DRAIN
120/60HZ
1
9
DC60-20054F
SCREW-TAPPING
1 - 4 x 1 4
4
1 0
DC97 - 00398B
ASSY - BASE
PP
1
11
DC61-30314A
BASE
PP
1
12
DC97-01224A
ASSY-LEG
2
13
DC61 - 50009B
LEG - ADJUST
FRPP
2
14
DC61 -50167A
LEG • RUBBER
BUTYL
4
15
DC60 - 20054F
SCREW-TAPPING
1-4
X
14
4
16
DC61 -20211A
{PAN - SILENT) SHUTTER
PP
1
17
-----------f8--------
DC60 - 20054F
------- nont - fini liin--------
SCREW - TAPPING
1-4
.'IPmm
9
5
BASE
19
DC60 - 20054C
SCREW-TAP.TH
1 - 4X 12
8
20
DC61 -20018P
HANDLE
PP
2
21
DC61 -00243A
GUIDE-FRAME
T2.6XW24XL535
1
(11}
