TECHNICAL SPECIFICATIONS
ALPHA 10 INTEGRATED AMPLIFIER
Output power ( 20Hz-20kHz at 0.5%THD) 100W, both channels into 80
now, single channel into 80, 1kHz
170W, single channel into 40, 1kHz
Harmonic Distortion, 100W, 80 at 1kHz 0.02% typical
Peak current rating ± 25 amps
L/R Crosstalk -80dB at 1kHz
INPUTS
Line inputs: Sensitivity 160mV
Noise (CCIR) ref. rated power -lOOdB
Input impedance lOkO
Overload margin 30dB
Pow er am plifier Sensitivity 740mV (Normal Gain)/1.0V (Low Gain)
Input impedance 7.5kO
Phono board (if fitted): Sensitivity 2.6mV MM, 260/.iV MC
Noise (CCIR) ref. rated power -79dB MM, -73dB MC
Input impedance 47kO MM, 3000 MC
Overload margin 35dB
O UTPUTS
Pream plifier O utput
Nominal output level 800mV
Maximum output level 8V
Output impedance 500
Tape/ AUX outputs:
Output impedance
I
500
Headphones:
Maximum output level into 6000 8V
Output impedance 1000
Mains voltage 230V/115V ±12%
Power consumption(max) 800VA (8VA Standby Mode)
Dimensions W/D/H mm. 430x380x110
Weight nett
packed
9.9kg
12.3kg
Supplied accessories Mains lead
CR35 Remote Handset (inc. batteries)
ALPHA 10P POWER AMPLIFIER
Output power ( 20Hz-20kHz at 0.5%THD) 100W, both channels, 80
1 low, single channel, 80, 1kHz
170W, single channel, 40, 1kHz
Harmonic Distortion, 60W, 80 at 1kHz 0.02% typical
Peak current rating ± 25 amps
Input impedance 7.5kO
Input sensitivity 740mV (Normal Gain)/1.0V (Low Gain)
Freguency response 10Hz-20kHz ±0.5dB
Noise (CCIR) ref. rated power -1 OOdB
Mains voltage 230V/115V ±12%
Power consumption(max) 800VA (8VA Standby Mode)
Size W/D/H mm. 430x350x110
Weight nett
packed
9.5kg
11.8kg
Supplied accessories Mains lead
E & O E .
