Diagnostics -
Flashes
Parking Light Flash Table
5 Slow
5 Fast
10
1 - pause - 2
2 - pause - 2
ON SOLID for 3
seconds^.
ON continuously
ON continuously
ON 2 seconds
ON 4 seconds
ON 20 seconds
ON 25 SEC.
IRREGULAR
CONSTANT
FLASHES
UP TO 60 SEC.
Description
Doors locked, Alarm and starter kill armed.
Run time has expired.
TRUNK
button pressed.
Remote start attempt cancelled by remote.
Doors unlocked, starter kill disarmed.
Exiting ignition valet
Entering cold weather mode
Entering ignition valet
Entering or exiting Ready Mode
Start signal received by the module.
Cold weather mode cancelled.
Exiting remote valet
Power-up reset.
Entering remote valet.
Entering extended run time.
+12 V detected on the brake input wire either while cranking or during run time.
Entering multi-speed tach programming.
Start attempt failed because no tach signal has been programmed.
Tach signal programmed.
New transmitter programmed.
A remote start was attempted while a tach-before-crank signal was detected before cranking.
Unit reset see “Resetting the Module” (p.1)
A ground (-) signal was detected on the hood pin input wire.
There was a remote start attempt while the vehicle was in valet mode.
Failed start: vehicle’s low battery voltage._______________________________
There was an attempt to start the vehicle while the module was in valet mode.
..followed by 1 flash
..followed by 3 flashes
ON SOLID for 3 seconds^
Idle mode: Idle mode is engaged
Run time: The vehicle has been remote started and is in run time.
While the brake
pedal is
pressed.
ON continuously
The hood has been opened and a ground (-) signal has been detected on the hood pin input
wire.
Locking or unlocking a door (with Door pulses configured to 4 sec.)
The hood pin has been flashed and you now have access to the programming options.
The Hood Pin-switch has been pressed twice: the Unit went into step 1 of the Programming
Centre procedure, and no Transmitter activity was detected for 20 seconds.
Or the Unit went into step 1 of the Transmitter Programming procedure and no activity was
detected for a few seconds. The Unit has exited the Transmitter Programming procedure.
If the unit gives irregular signals (1 to 10 flashes followed by a pause, followed by further
flashes), the system is playing back Start Failure Codes. This occurs when the Hood Pin-switch
is pressed three times.______________________________________________________________________
In Siren or Horn Mode: Alarm condition generated by an intrusion, by Panic Mode or when the
System is powered up.
To obtain a copy of the installation guide, please visit the
P. 8
Installation Guide
T W O - W A Y 6
■ B U T T O N
S T A R T E R
L C D
W I T H
M A N U A L
T R A N S M I S S I O N
R E M O T E
F U L L A L A R M S Y S T E M
Quick Installation Guide
To obtain a copy of the installation guide, please visit the
Table of Contents
...........1
...........1
...........1
...........2
...........2
Multi-speed
Tach Programming..................................... 6
How to Flash the Hood Pin
How to Flash the Hood Pin................................
Resetting the Module.........................................
Transmitter Programming Procedure.,
Entering Programming Options.......................
Programming Options.
Siren/Horn Honk Timing...........................................................6
Supplementary Information..................................................... 6
Fifth Relay Output (2nd IGN, ACC
or CRANK)............ 6
Tach jumper settings................................................................6
Testing........................................................................................7
Diagnostics - Parking Light Flash
Table................ 8
THE INSTALLER >
THE MODULE >
• Press and hold the hood pin for 4 seconds.
• Release the hood pin.
• While the parking lights are on, press down the hood pin once more
and release the hood pin immediately.
• You now have 20 seconds to select one of the sub-menus
Parking Lights “ON”
“ON” for 20 seconds
Resetting the Module
WARNING!
By resetting the module, all programmed values are erased — i.e.: tach, transmitter as well as
programming options. The programming options are returned to their default values.
1. Flash the hood pin (see above)
2. Once having reached the programming mode, the system will grant 10 seconds to complete the next step:
a) Press and release the break pedal 6
times
(within 10 seconds from entering programming mode).
The parking lights will flash 8 times to confirm the module is reset.
Transmitter Programming Procedure
1. Flash the hood pin (see p.1) — the parking lights will stay on for up to 20 seconds.
2. Before the lights go out, turn the ignition key to the
ignition
on
(
run
) position and immediately to the
OFF
position.
3. Press and hold the
lock
button and keep it down until the siren or horn chirps twice and the parking lights flash 5 times
quickly.
4. The transmitter has been stored in memory.
5. To exit: close the hood.
Notice
The manufacturer will accept no responsibility for any electrical damage resulting from improper installation of the product, be
that either damage to the vehicle itself or to the unit. This unit must be installed by a certified technician using all safety devices
supplied. Please note that this guide has been written for properly trained Autostart technicians: a certain level of skills and
knowledge is therefore assumed. Please review the installation guide carefully before beginning any work.
Warning
Before installing the unit, if installing on a vehicle with a
manua
l transmission, test that the OEM Door Switch contacts of the vehicle work
well, and that the Parking Brake system operates properly. If installing on a vehicle with an automatic
transmission
, test that the vehicle
does not start when the gearshift lever is in the “Drive” position. If it starts in gear, install a manual-transmission remote starter system
instead.
