PARTS LiST FOR MODELS 115-040A AND 1T5-050A
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1
Engine
2
710-0158
Hex Hd. Cap Scr. 5/16-24 x I’/V' Lg.*
3
11419—474
Deck Assembly—Complete (115-040A)
11420—474
Deck Assembly—Complete .(115-050A)
4
711-0555
Pivot Pin
5
714-0365
#6 Hi-Pro-Key 5/32 x %" Dia.
6
742-0123
Blade 20 inch (1 15-040A)
742-0125
Blade 22 inch (115-050A)
7
736-0217
Spring Lockwasher %" Scr. Heavy Duty
8
710-0459
Hex Hd. Cap Scr. %-24 x IVi" Lg.* Heat Treated
9
10769
Blade Adapter Kit
10
710-0117
Hex Hd. Cap Scr. 5/16-24 x 1" Lg. Heat Treated
11
10769
Blade Adapter Kit
12
736-0119
Spring Lockwasher 5/16" Scr.*
13
712-0123
Hex Nut 5/16-24 Thd.*
14
712-0123
Hex Nut 5/16-24 Thd.*
15
736-0119
Spring Lockwasher 5/16" Scr.*
16
726-0106
Push-on Flange Palnut
17
111 30—474
Adapter Plate
18
723-0253
Torsion Spring
19
11680—474
Chute Deflector Assembly
20
09392-504
Wheel Assembly—Complete (115-040A)
09392-505
Wheel Assembly—Complete (115-050A)
21
738-0213
Axle Bolt
738-0102
Axle Bolt (Use if your unit has Easy Height Adjustersjt
22
07006
Fortiflex Bearing
23
736-0105
Belleville Washer
24
714-0104
Hair Pin Cotter*
25
11191 —474
Protective Shield Assembly—Comp. (115-040A)
11197—474
Protective Shield Assembly—Comp. (115-050A)
26
710-0567
Hex Hd. Cap Scr. V4-28 x .62" Lg.
27
712-0107
Hex Center Lodknut 14-20 Thd,
28
710-0606
Hex Hd. Scr. ’/4-20 x 1.50" Lg.*
29
749-0111
Upper Handle (2-Required)
30
710-0136
Hex Hd. Cap Scr. '/4-20 x 1.75" Lg.*
31
720-0157
Grip
32
11609
Throttle Control Assembly—Complete
33
731-0180
Throttle Control—Cover
34
07470
Throttle Control—Knob
35
11598
Throttle Control—Assembly
36
746-0229
Conduit and Wire
37
749-0110
Lower Handle (115-040A)
749-0114
Lower Handle (1 15-050A)
38
10951
Height Adjuster Assembly Complete—R.H. (Optional)
10950
Height Adjuster Assembly Complete—L.H. (Optional)
39
07520
Gript
40
10949
Spring Lever Assembly with Knobt
41
736-0219
Spring Washert
42
712-0116
Elastic Locknut %-24 Thd.t
43
10934
Index Plate Assembly—R.H.t
10935
Index Plate Assembly—L.H.t
44
10937
Pivot Bart
45
710-0209
Sems Hex Hd. Cap Scr. %-16 x %" Lg.*t
46
746-0128
Cable Clip
47
710-0289
Hex Scr, '/4-20 X .50" Lg.*
tOptional Handle and Throttle Control.
*For faster service, obtain standard nuts, bolts, and washers locally.
If these items cannot be obtained locally, order by part number and
size as shown on parts list.
474—Citrus — When ordering ports if color or finish is important,
use the appropriate color code shown at left.
(e.g. Citrus Finish^! 1419(474)).
If repairs or service «
needed on the engine, please
contact your nearest authorized
engine service outlet. Check,
the
"Yellow!
Pages" of your
telephone book
under "Engines-
Gasoline."
