PARTS LIST FOR MODEL 117-530A
REF.
NO. PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1 09373 Control Rod
2 712-0262 Hex Ins. Jam Nut 3/8-24 Thd.
3 04563 Belt Clip
4 736-0300 FI. Wash.
5 756-0199 Flat Idler with Flange
6 12581 —463 Frame Ass’y-
8 736-0170 Special L-Wash. 5/16” Scr.
9 07386 FI. Wash. .406” I.D. X 1.25”
O.D. X .164
10 736-0169 Spring L-Wash. 3/8” Scr.
11 710-0152 Hex Scr. 3/8-24 x 1.00” Lg.
H.T.
14 712-0181 Hex Top L-Nut 3/8-16 Thd.
15 08324 —463 Belt Guard
16 736-0329 Spring L-Wash. V4”
Scr.*
17 712-0287 Hex Nut 1 / 4-20 Thd.*
18 12278 Idler Brkt. Ass’y- w. Brake
Shoe
19 09925 Sheave Ass’y.—4” Dia.
(Blade Spindle)
20 736-0921 Spring L-Wash. Vz" Scr.*
21 712-0200 Hex Ins. Nut 1 / 2-20 Thd.
22 09371 Brake Lever
23 736-0463 FI. Wash. .296I.D. X.62”
O.D. X.059
24 738-0234 Shoulder Scr. .500” Dia.
X.295
25 754-0109 “V”-Belty2"x43” Lg.
26 732-0158 Blade Tension Spring
27 756-0206 Engine Puiley 4.00” O.D.
28 712-0123 Hex Nut 5/16-24 Thd.
29 726-0111 Push Cap
*For faster service obtain standard nuts, bolts and washers
locally. If these items cannot be obtained locally, order by
part numberand size as shown on parts list.
(463—Top Flite Red)
When ordering parts, if color or finish is important, use the
appropriate color code shown at left. (e.g. Top Flite Red
Finish—11815(463)
The engine is not under warranty by the mower manufacturer. If repairs or service is needed on the
engine, please contact your nearest authorized dngine service outlet. Check the “Yellow Pages” of
your telephone book under “Engines — Gasoline.” Find It Fast
In The
Yellow Pages
11
