Chamberlain ATS 2113X User Manual
Owner’s manual
![background image](/manuals/72246/1/background.png)
Owner’s Manual
Please read this manual and the enclosed safety materials carefully!
■
Fasten the manual near the garage door after installation.
■
The door WILL NOT CLOSE unless the Protector System
■
®
is connected and
properly aligned.
Periodic checks of the opener are required to ensure safe operation.
■
The model number label is located on the front panel of your opener.
■
DO NOT exceed 8 complete cycles of door operation per hour.
■
The Chamberlain Group, Inc.
845 Larch Avenue
Elmhurst, Illinois 60126-1196
www.liftmaster.com
COMMERCIAL DOOR OPENER
Model ATS 2113X 1/2 HP
For Residential And Light Duty Commercial Use
Install on Sectional Doors Only
H
I
G
H
L
O
W
N O R
M
A
L
H
I
G
H
L
O
W
N O R
M
A
L
UP
FORCE
DOWN
FORCE
®
Table of contents
Document Outline
- Owner’s Manual
- TABLE OF CONTENTS
- INTRODUCTION
- ASSEMBLY
- INSTALLATION
- STEP 1 Determine the Header Bracket Location
- STEP 2 Install the Header Bracket
- STEP 3 Attach the Rail to the Header Bracket
- STEP 4 Position the Opener
- STEP 5 Hang the Opener
- STEP 6 Install the Door Control
- STEP 7 Install the Light
- STEP 8 Attach the Emergency Release Rope and Handle
- STEP 9 Electrical Requirements
- STEP 10 Install The Protector System
- STEP 11 Fasten the Door Bracket
- STEP 12 Connect Door Arm to Trolley
- ADJUSTMENT
- OPERATION
- CARE OF YOUR OPENER
- PROGRAMMING
- REPAIR PARTS
- ACCESSORIES
- WARRANTY
