53
Appendix A
Specifi cations
Appendices
Physical
Case: Fully-gasketed, high-impact plastic alloy, waterproof to IPX7
standards (waterproof to one meter for 30 minutes)
Size: 4.4”H x 2”W x 1.2”D
Weight: Approx. 5.3 ounces (150g) w/batteries
Temperature Range: 5° to 158°F (-15° to 70°C) 3 (operating)
P erformance
Receiver: Differential-ready, 12 parallel channel
Acquisition time: Approx. 15 seconds (warm start)
Approx. 45 seconds (EZinit/cold start)
Approx. 5 minutes (First Time/AutoLocate™)
Update Rate: 1/second, continuous
Position Accuracy: 3-5 meters (10-16 ft), 95% typical with DGPS corrections 1
<15 meters (49 ft) RMS, 95% typical 2
Velocity Accuracy: 0.05 meter/sec steady state
Dynamics: Performs to specifi cations to 6 g’s
Interfaces: NMEA 0183, RTCM 104 (for DGPS corrections) and
RS-232 for PC interface
Antenna: Built-In patch
Power
Input: Two 1.5-volt AA batteries 4
Power Consumption: 0.5 watts max.
Battery Life: Up to 18 hours of typical use in ‘Battery Saver’ mode 5
Specifi cations subject to change without notice.
1 With optional GARMIN Differential Beacon Receiver Input (such as GARMIN GBR 21 or 23).
2 Subject to accuracy degradation to 100m 2DRMS under the U.S. DoD-imposed Selective Availability
program.
3 Subject to proper user calibration
4 The temperature rating for the eTrex Legend may exceed the usable range of some batteries. Alkaline
batteries can rupture at high temperatures. External power can only be applied using the GARMIN
Auto Power Adapter (P/N 010-10203-00) or PC Interface Cable with Auto Power Adapter (P/N
010-10268-00). These cables contain a 12 VDC to 3VDC voltage regulator. Modifi cations or other
applications will void the product warranty.
5 Alkaline batteries lose a signifi cant amount of their capacity as temperature decreases. Use lithium
batteries when operating the eTrex Legend in below-freezing conditions. Extensive use of screen
backlighting will signifi cantly reduce battery life.
