SAFETY FEATURES
Your new chain saw is equipped with guard link safety chain
to reduce kickback.
A hand guard is provided to protect your hand from coming in
contact with the cutting chain in the event your hand slips off
the front handlebar or you lose control of the saw. Hand
guards do not eliminate the possibility of injury as a result of
kickback or loss of control.
THIS SAW INTENDED FOR
PROFESSIONAL USE ONLY.
HAND GUARD MOUNTING INSTRUCTIONS
1. Assemble the hand guard to the bend in the handlebar as
shown. Be sure alignment pin on guard is inserted in hole in
handlebar. Do not tighten the screws.
2. Make sure the hand guard is parallel to the handlebar.
Alternately tighten each hand guard mounting screw
maintaining an even gap between the hand guard and
mounting cap.
3. Tighten the mounting screws until the hand guard and
mounting cap are pulled together.
Caution; Screws must be tightened evenly to prevent
breakage.
SPUR MOUNTING
INSTALLING THE GUIDE BAR AND SAFETY CHAIN
Figure 1
[Bar Mounting ^
Figure 2
1. Remove the bar mounting nuts. Using the scrench packed
with your saw, loosen the nuts by turning counterclock­
wise. FIGURE 1.
2. Remove the bar clamp and outer guide bar plate. (Note
position of the guide plates.) F IGURE 2.
3. Place "S" clip over the mounting studs and flush to the
inner bar plate. Now mount the slotted end of the guide bar
over the bar mounting studs and "S" clip and behind the
clutch drum. Be sure to position the bar adjusting pin into
the hole in the guide bar. FIGURE 3.
Adjusting Pin
Hole
Figure 3
(continued}
