Cable Tie
(C)
FIGURES.
Rear
Frame
\
FIGURE 7.
ysr'/
/
Tubing
Connectors (K)
I
-6. Secure throttle control cable to handle with
cable ties (C) provided. See figure 6.
7. Check all nuts and bolts for correct tightness.
ASSEMBLY
Grass Catcher
1. Push the tubing connectors (K) onto the ends
of the rear frame. Slip the ends of the front
frame into the other ends of the tubing con
nectors. See figure 7.
2. Slip frame into grass bag. The black plastic is
the bottom of the grass bag. Fasten edges of
bag (with eyelets) to front frame with 3/8"
— bolts (G), lock washers (H) and hex nuts (I).
Finger tighten. See figure 8. Hint: For easier
assembly Do Not fasten lower bolts on sides
until after step 3.
Leave Bottom
Side Bolts Out
FIGURE 8.
