PARTS LIST FOR MODEL 110-328A AND 110-328-300
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1 710-0117 Hex Bolt 5/16-24 x 1.00" Lg.*
2 712-0237 Hex Cent. L-Nut 5/16-24 Thd.
3 13373 Cam Lever Ass’y-
4 720-0182 Knob—“T” Type
5 715-0247 Spring Pin Spiral
6 710-0192 Truss Mach. Scr. #10-24 x
.38" Lg.*
7 736-0147 Ext. L-Wash. #10 I.D.
8 712-0121 Hex Nut #10-24 Thd.*
9 14131 Catcher Frame Ass’y. Lower
Half N
10 750-0473 Tubing Connector N
13 749-0371 Frame—Rear Half N
14 728-0128 Rivet
15 12185 Reinforcement Bar
16 735-0168 Grass Catcher Flap
17 714-0115 Cotter Pin 1/8" Dia. x 1.00"
Lg.*
18 764-0174 Grass Catcher Bag
19 12192 Grass Catcher Adapter
20 732-0295 Torsion Spring
21 726-0135 Push Nut 5/16" Rod
22 738-0253 Hinge Rod
23 12395 Chute Door—Upper Half
24 748-0246 Roller Spacer
26 747-0141 Connecting Rod
27 738-0253 Hinge Rod
28 12194 Chute Door—Lower Half
29 12195 Hinge Bracket
30 12185 Reinforcement Bar
31 728-0131 Rivet .188 X .438
32 735-0167 Rear Protective Flap
33 12612 Rear Deck Section Ass’y.
34 12316 Reinforcement Bar
35 735-0183 Grass Catcher Flap
*For faster service, obtain standard nuts, bolts, and \washers locally. If these items cannot be obtained locally, order by part
number and size as shown on parts list.
(456—Radiant Tangerine) When ordering parts if color or finish is important, use the appropriate color code shown at left,
(e.g. Radiant Tangerine Finish—12191 (456).)
The engine is not under warranty by the mower manufacturer. If repairs or service is needed on the
engine, please contact your nearest authorized engine service outlet. Check the “Yellow Pages” of
your telephone book under “Engines — Gasoline.” Find It Fast
In The
Yellow Pages
19
