Troy-Bilt 466 - Manual (Page 19)

Model 466
Ref.
No. Part No. Part Description Ref.
No. Part No. Part Description
1. 747-2136 Lower Bail Handle 49. 731-1404A Mulch Plug
2. 647-0004 Blade Control Handle 50. 731-1409 Discharge Deflector SD
3. 749-1501 Upper Handle 51. 710-0599 rr Screw 1/4-20x0.5”
4. 710-1270 Oval C-Sunk Scr. 1/4-20 x 1.31” 52. 736-0270 Bell Washer 0.265” X 0.75”
5. 746-0883 Control Housing 53. 782-5002 Front Baffle
6. 712-0324 Hex Lock Nut 1/4-20 54. 618-0657 Transmission Assembly Compì.
7. 746-0551 Control Cable; 43” 55. 7510042824 Screw #12 x 0.457”
8. 749-0928A Lower Handle 56. 731-2601 Front Drive Cover
9. 746-1146 Drive Cable 57. 715-0169 Roll Pin
10. 710-0606 Hex Screw 1/4-20 x 1,5” 58. 736-0331 Bell Washer
11. 710-1174 Carriage Bolt 59. 748-0355 Bearing Support
12. 720-0284 Handle Knob 60. 736-0447 Wave Washer
13. 736-0451 Saddle Washer 61. 782-0511A Height Adj. Plate LH
14. 720-0279 Wing Nut 782-0512B Height Adj. Plate RH
15. 710-1205 Rope Guide 62. 682-0509 Pivot Plate Assembly
16. 764-0310 Grass Catcher Frame: Rear 63. 756-1146A Drive Pulley
17. 764-0311 Grass Catcher Frame: Front 64. 748-0411 Blade Adapter
18. 631-0075B Engine Spacer Assembly 65. 742-0741 Mulching Blade w/Star: 21”
23. 714-0104 Hairpin Clip 66. 712-0324 Hex Lock Nut
24. 731-1236 Rear Trail Shield 67. 710-0216 Hex Screw
25. 732-0700 Wire: Trail Shield 68. 715-0221 Dowel Pin
26. 720-0275 Knob 69. 717-1762 Gear 14TRH
27. 710-0192 Scr. Tr. Mach. #10-24 X 0.380” 717-1761 Gear 14TLH
28. 732-0677 Torsion spring LH 70. 714-0101 Hairpin Clip
29. 782-5003 Rear Baffle LH 71. 736-3013 Flat Washer
30. 710-1017 Scr. AB 1/4-14x0,625” 72. 716-0865 Snap Ring
31. 732-0678 Torsion Spring RH 73. 782-7551 Wheel Dust Cap
32. 710-0896 Hex Scr. w/Wash. 1/4-14 x 0.62“ 74. 716-0102 Snap Ring
33. 720-0426 Knob 75. 736-0474 Washer DD 1,5“ O.D.
34. 736-0105 Bell Washer .375 x .870 76. 756-1231 Input Pulley
35. 734-2004A Wheel: Rear 77. 710-1257 Hex Bolt
36. 738-0102 Shoulder Screw 78. 736-0452 Bell Washer
37. 731-0981A Hubcap 79. 664-0176 Grass Bag
38. 682-0513 Handle Bracket Assembly LH 80. 782-5004 Rear Baffle RH
682-0514 Handle Bracket Assembly RH 82. 750-1166 Slev. Spacer LH
39. 14766 Pivot Bar LH 750-1165 Slev. Spacer RH
14765 Pivot Bar RH 83. 682-0516A Height Adj. Assembly RH Compì.
40. 732-0706 Front Lever RH 84. 682-0515A Height Adj. Assembly LH Compì.
732-0707 Front Lever LH 85. 782-7000 RD Chute Door
41. 738-0507B Shoulder Screw 87. 732-0731 Torsion Spring
42. 747-0710 Hinge Pin 88. 726-0240 Cable Tie (not shown)
43. 782-7006 Mounting Bracket 89. 710-1008 IT Screw
44. 712-0798 Hex Nut 90. 682-0512A Height Adj. Assembly RH Compì.
45. 736-0356 Flat Washer 91. 682-0511A Height Adj. Assembly LH Compì.
46. 732-1043 Belt Tension Spring 92. 710-1248 Weld Pin
47. 782-0082A 3-in-1 Deck: 21” 93. 734-2042 Wheel: Front
48. 754-0637 V-Belt 94. 732-0417A Spring Lever
