PARTS LIST FOR LEAF BLOWER MODELS 249-688A AND 249-690A
Ref.
No.
PART
No.
COLOR
CODE DESCRIPTION
New
Part
1 Engine (3) or (5) H.P.
2 710-0118 HexScr. 5/16-18 X.75" Lg.*
3 13739 Engine Plate Assembly N
4 710-0528 Hex Scr. 5/16-18 X 1.25" Lg.*
5 710-0405 Curved Hd. Carriage Bolt 5/16-18 x 1.75
6 2142-073 Throttle Control Complete
7 712-0162 Hex L-Nut #10-32Thd.
8 1710-053 Grip - Handle
9 1509-003 HexScr. #10-32 X 1.25" Lg.
10 3712-163 Upper Handle
11 09966 Hand Knob
12 3712-106 Lower Handle
13 736-0119 L-Wash. 5/16" Scr.*
14 712-0267 Hex Nut 5/16-18Thd.*
15 712-0267 Hex Nut 5/16-18 Thd.*
16 2631-043 Axle
17 716-0106 "E" - Ring
18 2108-220 Wheel Assembly Complete
19 736-0290 Fl.-Wash. 21/32 x 1.0" x 1/16 Thk.
20 1624-165 Wheel Spacer
21 712-0267 Hex Nut 5/16-18 Thd.*
22 11452 Mounting Plate
23 710-0117 Hex Scr. 5/16-24 X 1.00" Lg.*
24 710-0118 Hex Scr. 5/16-18 X .75" Lg.*
25 736-0217 L.-Wash. 3/8" Scr. Heavy Duty
26 712-0241 Hex Nut 3/8-24 Thd.*
27 712-0113 Wing Nut 1/4-20 Thd.
28 736-0173 Fl.-Wash. 1/4" I.D.
29 13742 Deflector - Chute N
30 13741 Deflector N
31 710-0134 Carriage Bolt 1/4-20 x .62" Lg.
32 2192-002 Caster Assembly
33 1548-021 Roll Pin
34 13738 Guard Assembly N
35 13796 Impeller Guard N
36 13735 Housing Assembly Complete N
37 710-0152 Hex Scr. 3/8-24 X 1.00" Lg.*
38 736-0169 L-Wash. 3/8" Scr.*
39 07386 Fl.-Wash.
40 12230 Air Vane
41 ,13734 Vane Plate Assembly N
42 721-0128 Gasket
43 714-0133 Sq. Key 3/16 X 3/16 x 1.50" Lg.
44 726-0178 Cable Tie
45 40301 Spacer
*For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order by part
number and size as shown on parts list.
(436 - Radiant Yellow) When ordering parts if color or finish is important, use color code shown at left. (e.g. Radiant
Yellow Finish- 11907 (436).
The engine is not under warranty by the mower manufacturer. If repairs or service is needed on the
engine, please contact your nearest authorized engine service outlet. Check the “Yellow Pages" of
your telephone book under “Engines — Gasoline.”
