Models 645C, 647C, 648C and 650C
PARTS LIST FOR SHREDDERS
REF.
NO.
PART
NO.
CODE
DESCRIPTION
REF.
NO.
PART
NO.
CODE
DESCRIPTION
1
742-0571
Blade
42
781-0474A
Flail Housing Ass’y.—R.H.
2
710-0818
Hex Patch Bolt 3/8-24 x 2" Lg.
43
735-0639
Spark Plug Boot (Optional)
(Gr. 8)t
44
—
Engine
710-1254
Hex Patch Bolt 3/8-24 x 2.25"
45
747-0531A
Release Bar
(Gr. 8)tt
46
732-0546
Torsion Spring 1.06" Lg.
3
714-0114
Sq. Key 1/4
X
2.0" Lg.f
47
712-0429
Elastic Lock Nut 5/16-18 Thd.
4
736-0217
L-Wash. 3/8" I.D. H.D.
48
710-0601
Hex Wash. Hd. Self-Tap Scr.
5
736-0247
FI-Wash. .406" I.D. x 1.25" O.D.
5/16-18
X
.75" Lg.
Hdn.
49
11480
Stop Washer
6
11459B
Flail
50
736-0264
FI-Wash. 5/16" I.D.
7
711-0564
Flail Spacer
51
710-0542
Hex Bolt 5/16-18x8.38" Lg.
8
711-0833A
Clevis Pin .496" Dia.
52
781-0487B
Back-Up Plate
9
711-0834
Flail Spacer W/.160" Dia. Hole
53
16522B
Inlet Guide Ass'y.
10
715-0249
Spring Roll Pin 1.12" Lg.
54
781-0494
Pivot Hopper Hood
11
736-0192
FI-Wash. .531" I.D. x .94" O.D.
55
16524B
Upper Guide Ass’y.
12
681-0002
Impeller Ass’y- Comp. (Incl. Ref.
56
710-0286
Truss Mach. Scr. 1/4-20 x .5"*
1,6, 7, 8, 9, 10, 11, 12, 13,
57
712-0107
Hex L-Nut 1/4-20 Thd.
14)t
58
11461B
Upper Leaf Ramp Section
681-0030
Impeller Ass’y- Comp. (Incl. Ref.
59
726-0214
Push Cap 5/8" Dia. Rod
1,6, 7, 8, 9, 10, 11, 12, 13,
60
737-0195
Drain Elbow (645C & 647C)
14)t
737-0125
Drain Elbow (650C)
13
742-0490
Chipper Blade
61
750-0786
Spacer .64" I.D. x .38" Lg.
14
710-1054
Flat Hd. Scr. 5/16-24
X
.75“ Lg.
62
738-0814
Shredder Axle (645C)
15
712-0411
Hex Top L-Nut 5/16-24 (Gr. 5)
738-0813
Shredder Axle (647C, 648C &
16
736-0119
L-Wash. 5/16" I.D.*
650C)
17
710-0825
Hex Bolt 1/4-20 x 3.75" Lg.*
63
734-1600
Wheel Ass’y. Comp. (645C)
18
736-0142
FI-Wash. .281" I.D. x .5" O.D.
734-1597
Wheel Ass’y. Comp. (647C,
19
750-0793
Chute Hinge Spacer 1.66" lg.
648C & 650C)
20
711-0835
Clevis Pin .5" Dia. x 4.62" Lg.
64
734-1455A
Rim Only (647C, 648C & 650C)
22
712-0291
Hex Ctr. L-Nut 1/4-20 Thd.*
65
741-0487A
Flange Bearing .632" I.D.
23
714-3010
Cotter Pin
(647C, 648C & 650C)
24
781-0457
Shredder Screen
66
734-0255
Air Valve (647C, 648C & 650C)
25
714-0149B
Internal Cotter Pin 3/8" Dia.
67
737-0211
Grease Fitting (647C, 648C &
26
781-0480
Chute Deflector Ass’y.
650C)
27
712-3010
Hex Nut 5/16-18 Thd. (Gr. 5)
68
710-0895
Hex Hi-Low Scr. 1/4" x .75" Lg.
28
736-0242
Bell-Wash. .345" I.D. x .88"
(650C)
29
720-0170
Hand Knob
69
710-3038
Hex Bolt 5/16-18
X
.88" Lg.
30
747-0744A
Chipper Door Rod
(650C)
31
732-0542
Torsion Spring 1.14" Lg.
70
726-0205
Hose Clamp (650C)
32
781-0489
Chipper Door
71
751-0535-7
Fuel Line—7" Lg. (650C)
33
781-0475
Chipper Chute Ass’y.
72
751-0570
Fuel Tank Ass’y. Comp. (650C)
34
736-0170
Spec. L-Wash. 5/16" I.D.
73
781-0497
Fuel Tank Mtg. Brkt. (650C)
35
712-3010
Hex Nut 5/16-18 Thd. (Gr. 5)
74
781-0498
Fuel Tank Support Brkt. (650C)
36
781-051OA
Shredder Frame
75
732-0629
Torsion Spring
37
710-0157
Hex Bolt 5/16-24 x .75" Lg.
76
747-0747
Hopper Door Rod
38
736-0119
L-Wash. 5/16" I.D.*
77
781-0492
Hopper-Pivot Door
39
710-3008
Hex Bolt 5/16-18
X
.75" Lg.
78
781-0493
Hopper Lockout Brkt.
(Gr. 5)
79
726-0106
Cap Speed Nut 1/4" Rod
40
710-0380
Hex Bolt 5/16-18
X
1.75" Lg.*
—
764-0199A
Bag (Not Shown)
41
681-0004
Flail Housing Ass’y.—L.H.
—
723-0400
Safety Glasses (Not Shown)
fUsed with Keyed Engine Crankshaft.
ttUsed with Tapered Engine Crankshaft.
7B — Page 7
