MTD Duerr 248-623-003 - Manual (Page 15)

PRO/20 (Model 622)
PRO/22 (Model 623)
PARTS LIST FOR MODELS 622 and 623 LOG SPLITTERS
EF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1 710-1010 Hex Bolt 1/2-20 x 3" Lg. 43 726-0146 Adjustable Hose Clamp
(Grade 8) N 44 727-0308 Suction Hose -20" N
2 710-1018 Hex Bolt 1/2-20 x 2.75" 45 727-0310 Pressure Hose N
Lg. (Grade 8) N 46 736-0119 L-Wash. 5/16" I.D.*
3 710-3029 Hex Bolt 7/16-20 x 1.25" 47 737-0234 90° Swivel N
Lg. N 48 781-0097 Rear Coupling Support
4 712-0240 Hex Jam Nut 7/16-20 Thd. Brkt.
5 712-0333 Hex Nut 1/2-20 Thd. 49 781-0098 Front Coupling Support
(Grade 8) N Brkt.
6 714-0470 Cotter Pin 1/8 Dia. 50 712-0299 Hex Slotted Nut 3/4-16
7 736-0921 L-Wash. 1/2" I.D.* Thd.
8 738-0736 Hinge Pin 1/2" Dia. N 51 714-0162 Cotter Pin 5/32" Dia.
9 781-0127 Fixed Side Gib N 52 734-0873 Hub Cap
10 781-0129 Adjustable Gib N 53 734-1016 Wheel Ass'y. Comp.
11 781-0130 Adjustable Gib Shim N 734-0872 Tire Only
12 781-0132 Beam (Kss'y. AiSE /Si-013! N 734-1017 Rim Only
13 781-0140 Wedge Ass'y. N 734-0255 Air Valve
14 781-0142 Wedge Back Plate N 54 741-0107 Roller Bearing A. PEft. IdHREl •
15 710-0672 Hex Bolt 5/16-24 x 1.25" 56 736-0351 Fl.-Wash. .76" I.D. x 1.5"
Lg.* O.D.
16 711-3104 Clevis Pin 57 750-0442 Spacer 1.56" Lg.
17 712-3057 Hex Nut 5/16-24 Thd. 58 723-0405 Filter Element N
(Grade 5) 59 723-0406 Filter Head N
736-0119 L-Wash. 5/16" I.D.* 60 727-0309 Return Hose — 30" N
V,2
781-0273 Pivot Latch Brkt. N 61 710-3144 Hex Bolt 3/8-16
X
2"
23 Engine Lg. (Grade 5)
24 781-0148 Tank Ass'y. Complete N 62 712-0430 Hex L-Nut 3/8-16 Thd.
25 710-0409 Hex Bolt 5/16-24 x 1.75" 63 781-0168 Stripper Half » N
Lg.* 64 710-0521 Hex Bolt 3/8-16x 3" Lg.
26 712-0123 Hex Nut 5/16-24 Thd.* (Grade 8)
27 736-0119 L.-Wash. 5/16" I.D.* 66 710-3130 Hex Bolt 3/8-16
X
3.25"
28 737-0236 Vent Plug N Lg. (Grade 8) N
29 717-0885 Hydraulic Cylinder** N 67 711-0813 Clevis Pin 5/16" Dia. N
30 717-0886 Control Valve- N 69 712-0375 Hex L-Nut 3/8-16 Thd.
31 727-0307 Metal Pressure Tube N 70 712-0798 Hex Nut 3/8-16 Thd.*
32 737-0235 3/4" Hose Barb N 71 713-0338 Tow Hitch Chain
33 737-0238 Pipe Nipple N 72 732-0194 Spring Pin
34 737-0192 Elbow 73 727-0311 Hitch Coupler
35 710-0117 Hex Bolt 5/16-24 x 1.0" 74 736-0169 L-Wash. 3/8" I.D.*
Lg.* 75 736-0185 Fl.-Wash. .406" I.D. x .75"
36 710-0237 Hex Bolt 5/16-24 x .62" O.D.
Lg.* 80 781-0160 Tongue N
37 710-0363 Hex Bolt 5/16-24 x 4" Lg. 81 781-0162 Jack Stand N
(622) 82 750-0507 Spacer 3/8" I.D. x .27" Lg.
710-0968 Hex Bolt 5/16-24 x 5" Lg. 83 710-0157 Hex Bolt 5/16-24 x 3/4"
(623) Lg, (Grade 5) t
38 712-0123 Hex Nut 5/16-24 Thd.* 84 781-0271 Fender t N
39 714-0122 Sq. Key 3/16" x .75" -
85 781-0272 Fender Support t N
40 717-0887 Pump J-ET SOPl. ¿a/i£AJ XO. w HG 86 736-3014 Fl.-Wash. .78" I.D. x 2.0"
41 717-0891 Flexible Coupling N O.D. N
42 719-0278 Coupling Shield (622) 87 736-0159 Fl.-Wash. .344" I.D. x .88"
719-0281 Coupling Shield (623) O.D.
For faster service order standard nuts, bolts, and washers locally. If these items cannot be obtained locally, order by part
number and size as shown on parts list.
**Hydraulic cylinder "0" ring kit available - order part number 753-0458. h i
t PRO/22 (Model 623) Only.^ lil-OX/D ¿} U. ^TAhlt J
15
