Model 650
PARTS LIST FOR MODEL 650 SHREDDER
Ref.
No.
Part
No.
Color
Code
Description
New
Part
Ref.
No.
Part
No.
Color
Code
Description
New
Part
1
11476
Door Chip It
31
714-0144
Cotter Pin 1/8" Dia. x 1.00"
2
710-0465
Hex Bolt 1/2-20 x 4.50" Lg.*
Lg.* (Special)
3
711-0580
Clevis Pin
32
736-0192
Fl.-Wash. .531" I.D. x 937
4
711-0579
Flail Spacer 7/32" Lg.
O.D.
X
.09
5
11455
Cutting Finger
33
11459
Flail
6
736-0921
L-Wash. 1/2" I.D.*
34
711-0564
Flail Spacer 23/32" Lg.
7
726-0111
Palnut 3/16" Dia.
35
711-0578
Clevis Pin .50" Dia. x 3.0" Lg.
8
712-0922
Hex Jam Nut 1/2-20 Thd.*
36
736-0247
Fl.-Wash. .406" I.D. x 1.25"
9
714-0507
Cotter Pin 3/32" Dia. x 3/4"
O.D. Hdn.
Lg-
37
736-0217
L.-Wash. 3/8" I.D. H.D.
10
16568
Chute Defleotor
N
38
710-0151
Hex Bolt 3/8-24 x 2.0" Lg. H.T.
11
712-0107
L.-Nut 1/4-20 Thd.
39
14575-463
Flail Housing Ass'y.-Comp.
12
710-0289
Hex Bolt 1/4-20 x .50" Lg.*
40
732-0546
Torsion Spring .062 Dia. x 1.06
N
13
714-0114
Sq. Key 1/4" x 2.00" Lg.
Lg.
14
13430
Impeller Assembly
41
11477
Chip-lt Guide Ass'y.
15
710-0157
Hex Bolt 5/16-24 x 3/4" Lg.
42
11478
Hinge Pin
16
736-0119
L.-Wash. 5/16" I.D.*
43
747-0531
Release Bar
N
17
14573
Hopper to Engine Mtg. Plate
44
712-0109
Wing Nut Elastic 1/4-20 Thd.
18
Engine
45
13431
Blade
19
11464
Engine Mounting Plate
46
11460-463
Upper Leaf Ramp Section
20
712-0123
Hex Nut 5/16-24 Thd.*
47
16524-463
Lower Leaf Ramp Section
N
21
736-0119
L.-Wash. 5/16" I.D.*
48
736-0264
Fl.-Wash. 5/16" I.D.
22
738-0521
Shaft
49
11481-463
Hopper Assembly
23
736-0170
Special L.-Wash. 5/16" I.D.
50
710-0601
Hex Wash. Hd. Self-Tap Scr.
24
726-0221
Push Cap
5/16-18
X
.75" Lg.
25
711-0494
Spacer
52
11454
Back-Up Plate
26
734-1056
Wheel Ass'y.-Comp.
53
16522
Inlet Guide Assembly
N
27
736-0100
Fl.-Wash. .50" I.D.
55
11480
Stop Washer
28
710-0624
Hex Bolt 5/16-24 x 1.50" Lg.*
56
710-0542
Hex Bolt 5/16-18
X
8.38" Lg.
29
712-0429
Elastic Lock Nut 5/16-18 Thd.
57
735-0639
Spark Plug Elbow (Optional)
30
710-0237
Hex Bolt 5/16-24 x .62" Lg.*
764-0199
Bag (Not Shown)
N
—
723-0400
Safety Glasses Not Shown
N
*For faster service obtain standard nuts, bolts and washers locally. If these items cannot be obtained locally, order part
number andTsTzeass) shown on parts list.
463—Topflite Red
621 —Brilliant Firemist (24650)
When ordering parts if color or finish is important, use color code shown at left,
[i.e. (part no.)—463 for Topflite Red Finish].
The engine is not under warranty by the shredder manufacturer. If repairs or service is needed on the engine,
please contact your nearest authorized engine service outlet. Check the "Yellow Pages" of your telephone
book under "Engines—Gasoline."
Find n Fast
In The
Yellow Pages
NOTE
Specifications subject to change without
notice or obligation.
