rr,/^ C r ^ MODEL NUMBtE'^ t5H42D

iCHEMATiC

BLACK

IGNITION SWITCH

POSITION

CIRCUIT

“MAKE”

OFF

G + M + L

NONE

RUN/LIGHT

B + L

A + Y

RUN

B + L

NONE

START

B + L + S

NONE

YOUR TRACTOR 13

EQUIPPtD Y/ITH A SPECIAL

ALTERNATOR SYSTEM,
THE LIGHTS ARE NOT
CONNECTED TO THE
BATTERY, BUT HAVE THEIR
OWN ELECTRICAL SOURCE.
BECAUSE OF mis THE
BRIGHTNESS OF THE LIGHTS
WILL CHANGE WITH ENGINE
SPEED. AT IDLE THE LIGHTS

will

dim

the

engine

SPEEDED UP. THE LIGHTS
WILL BECOME THEIR BRIGHTEST.

NON-REMOVABLE

CONNECTIONS

REMOVABLE

CONNECTIONS

WIBiNG INSULATED CLIPS

NOTE: IF VtfIRING INSULATED CLIPS WERE REMOVED FOR
SERVICING OF UNIT, THEY SHOULD BE REPLACED TO
PROPERLY SECURE YOUR WIRING.
