Models 635, 636 and 637
PARTS LIST FOR MODELS 635, 636 AND 637 LOG SPLITTERS
REF.
NO.
PART
NO.
CODE
DESCRIPTION
REF.
NO.
PART
NO.
CODE
DESCRIPTION
1
712-0359
Slotted Nut 3/4-16 Thd.
46
715-0116
Roll Pin
2
714-0162
Cotter Pin 5/32" Dia.
47
727-0311
Hitch Coupler
3
734-0873
Hub Cap
49
736-0116
FI-Wash. .635" I.D. x .93" O.D.
4
734-1016
Wheel Ass’y. Comp.
50
736-0169
L-Wash. 3/8" I.D.*
734-0872
Tire Only
51
736-0185
FI-Wash. .406" I.D. x .75" O.D.
734-1017
Rim Only
52
750-0497
Spacer .44" Lg.
734-0255
Air Valve Only
53
781-0162
Jack Stand
5
736-0351
FI-Wash. .76"I.D. x1.5"O.D.
54
781-0399
Tongue Tube
6
741-3028
Bearing Cone
55
781-0370A
Locking Rod
7
736-0921
L-Wash. 1/2" I.D.*
56
781-0398
Beam Support Ass’y.
8
737-0192
90° Solid Male Adapter
57
723-0405
Filter Element
9
737-0238
Pipe Nipple 1/2 NPT
58
723-0406
Filter Head
10
741-3029
Bearing Cup
60
727-0443
Return Hose 3/4“ I.D. x 44" Lg.
11
737-0265
90° Male Adapter
61
781-0538
Hose Guard (637)
12
736-0192
FI-Wash. .531" I.D. x .94" O.D.
62
681-0014
Vertical Beam Ass’y.
13
710-0514
Hex Cap Scr. 3/8-16 x 1" Lg.
66
714-0470
Cotter Pin 1/8" Dia.
15
710-1018
Hex Bolt 1/2-20
X
2.75" Lg.
68
738-0805
Hinge Pin 1/2 x 4.8" Lg.
(Grade 8)
73
710-0117
Hex Bolt 5/16-24
X
1" Lg.
16
710-1032
Hex Bolt 3/8-24 x 1.5" Lg.
74
710-0237
Hex Bolt 5/16-24
X.
62" Lg.
17
712-0239
Hex L-Nut 1/2-20 Thd.
75
710-0363
Hex Bolt 5/16-24
X
4" Lg.
19
712-3001
Hex Jam Nut 3/8-24 Thd.
76
712-0123
Hex Nut 5/16-24 Thd.
(Grade 5)
77
714-0122
Sq. Key 3/16“
X.
75"
21
732-0583
Comp. Spring 4" Lg.
78
717-0891
Flexible Coupling
23
781-0323B
Wedge Ass’y.
79
717-0936
Gear Pump
24
781-0537
Back Plate
80
719-0278
Coupling Shield
1 25
781-0350A
Fixed Side Gib
81
726-0132
Hose Clamp 5/8"
26
781-0351
Adjustable Gib
82
727-0451
Suction Hose
27
781-0352A
Adjustable Gib Shim
83
727-0452
High Pressure Hydraulic Hose
28
781-0356
Floating Gib Plate
48"
29
714-0203
External Cotter Pin
84
736-0119
L-Wash. 5/16" I.D.*
30
715-0216
Cylinder Mounting Pin
85
781-0097
Rear Coupling Support Brkt.
31
718-0246
Hydraulic Cylinder
86
781-0098
Front Coupling Support Brkt.
32
717-0899
Control Valve
87
710-0157
Hex Bolt 5/16-24
X
.75" Lg.
33
727-0323
Metal Pressure Tube
88
710-0409
Hex Bolt 5/16-24
X
1.75" Lg.
34
781-0526
Hose Guard (637)
89
—
Engine
35
737-0153
Return Elbow
90
736-0159
FI-Wash. .344" I.D. x .875" O.D.
36
737-0279
Adapter
91
737-0236
L-Vent Pipe Plug
37
737-0235
3/4" Hose Barb.
92
735-0639
Spark Plug Boot (Optional)
38
726-0174
Hose Clamp
93
781-0556
Fender (Optional)
39
710-0521
Hex Bolt 3/8-16
X
3" Lg.
95
681-0011A
N
Frame Weldment (635 & 637)
(Grade 8)
681-0085
N
Frame Weldment (636)
40
710-0411
Hex Bolt 3/8-16
X
4" Lg.
96
720-0235
Grip
41
710-0944
Hex Bolt 3/8-16
X
4.25" Lg.
97
747-0583
Control Handle
(Grade 5)
98
732-0194
Spring Pin
42
711-0813
Clevis Pin 5/16x2.5" Lg.
99
781-0525
Dislodger
43
712-0375
Hex L-Nut 3/8-16 Thd.
102
750-0750
Spacer 1/2" I.D. x .86" Lg.
44
712-0798
Hex Nut 3/8-16 Thd.
103
721-0168
Bearing Seal Only
45
713-0433
Chain—^Tow Hitch
104
736-0262
FI-Wash. 3/8" I.D. x .87" O.D.
‘For faster service obtain standard nuts, boits and washers iocaily.
If these items cannot be obtained locally, order by part number
and size as shown on parts list.
