ASSEMBLY

Your new tiller has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To
ensure safe and proper operation of your tiller all parts and hardware you assemble must be tightened securely. Use the correct
tools as necessary to insure proper tightness.

TOOLS REQUIRED FOR ASSEMBLY

A socket wrench set will make assembly easier. Standard
wrench sizes are listed.

(1) Utility knife

(1) Screwdriver

(2) 1/2" wrenches

OPERATOR’S POSITION (See Fig. 1)

When right or left hand is mentioned in this manual, it means
when you are in the operating position (standing behind tiller

handles).

LEFT

FRONT

fiiQn

RIGHT

OPERATOR'S

POSITION

FIG. 1
