Troy-Bilt 13076-GTX 20 - Manual (Page 19)

Models 13074 and 13076
Ref. Part Description Qty. Ref. Part Description Qty.
53 1765531 Cable Tie................................................... . A/R 129 1754242 Right Lense....................................... . ....... 1
82 1107381 Flat Washer, 1/4......................................... . 4 130 1750963 Flat Head Screw, #6-32 x 1/2................. ....... 5
83 1100241 Lock Washer, 1/4........................................ . 2 131 1754607 Speed Control Switch........................... ....... 1
93 1185985 KepsNut, #10-24......................................... . 2 132 1754189 Light Switch....................................... ....... 1
98 1734398 Toplock Nut, 1/4-20..................................... 2 133 1754608 PTO Switch................... .................... ....... 1
107 1747738 J-Clip........................................................ . 2 134 1757364 Hour Meter........................................ ....... 1
108 1115815 Truss Head Phillips Bolt #10-24 x 5/8... 1 135 1757357 Lense................................................ ....... 1
109 1751328 Interlock Switch Switch................................ . 2 136 1755647 Fuel Gauge........................................ ....... 1
110 1738463 Semms Bolt, #12-24 x 1/2............................. . 2 137 1738462 Clutch............................................... ....... 1
111 1185130 Semms Bolt, #10-24 x 3/4............................. . 1 138 1769917 Positive Cable.................................... ....... 1
112 1772131 Battery..................................................... . 1 139 1769918 Negative Cable................................... ....... 1
113 1755802 Battery Cover............................................. . 1 140 1100805 Hex Screw, 1/4-20 x 3/4....................... ....... 2
114 1749907 Relay........................................................ . 1 141 1752586 Hook Screw........................................ ....... 2
116 1754207 Ignition Switch............................................ . 1 143 1752132 Voltage Sensor.................................... ....... 1
117 1753986 Key.......................................................... , 1 211 1186389 Flange Nut, 1/4-20.............................. .......
4
118 1769919 Main Harness.............................................. . 1 372 1756032 Lead Assembly.................................... ....... 1
119 1755487 Grommet............ ...................................... . 2 580 1767104 Lense................................................ ....... 1
120 1768882 Seat Switch................................................ . 1 581 1753788 Retainer............................................ ....... 4
122 1765953 Fuel Sender................................................ . 1 582 1752871 Headlight Assembly............................. ..... 4
123 1745778 Hex Semms Bolt (Incl. washer) 583 1752872 Bulb.................................................
..... 4
#10-32x1/2............................................. .
5 584 1731453 Pan Head Screw.................................. ........ 2
124 1754259 Shield....................................................... . 2 585 1805365 Flat Washer....................................... ....... 2
125 1752871 Light Assembly............................................ . 2 586 1754194 Gasket.............................................. ....... 2
126 1186229 Hex Nut, 1/4-20.......................................... . 2 587 1735285 Bulb................................................. .......
5
127 1754191 Gasket...................................................... .
4 588 1752505 Headlight Harness............................... ....... 1
128 1754241 Left Lense................................................. . 1 589 1752875 Socket Only........................................ ........ 2
A/R As required.
19
