ModeM3076
Ref. Part Description Qty. Ref. Part Description Qty.
5 1186347 Flange Screw, 3/8-16 x 1........... . 2 203 1771430 Arm Assembly, Control (D).......... 1
7 1186393 Flange Locknut, 3/8-16............. . 2 204 1717897 Hair Pin......... ....................... 2
40 1100045 Hex Screw, 5/16-18x1.............. . 1 205 1713457 Drive Pin.............................. . 2
53 1735531 Cable Tie.............................. . A/R 206 1767407 Valve Link..... ......................... 1
156 1186391 Locknut, 5/16-18.................... . 4 207 1737018 Flange Bearing...................... . 4
158 1717563 Connector............................. . 1 208 1767406 Valve Link........... .................. 1
159 1185737 Elbow, 90°............................ . 2 209 1767393 Valve.......... .......... .... ........... 1
161 1767741 Tube (Control Valve E to Lift Valve In).. . 1 (Replacement Seal Kit see Ref. 560)
164 1767746 Tube (Control Valve A to Tee)..... . 1 210 1186316 Hex Screw, 1/4-20 x 2..... ... ;..... 2
171 1722667 Tubing Clamp......................... . 1 211 1186389 Flange Nut, 1/4-20................... 2
173 1186230 Hex Nut, 5/16-18.................... . 1 212 1769391 Connector.............................. . 2
174 1185739 Elbow, 90°............................ . 1 213 1767747 Tube (Tee to Filter In)....... ....... 1
181 1186330 Flange Screw, 5/16-18x7/8........ . 2 214 1762308 Swivel Tee............................. 1
182 1186330 Flange Screw, 5/16-18 x 7/8....... . 2 216 1767744 Tube (Lift Valve B to
183 1767725 Bearing................................ . 2 Lift Cylinder, Fixed End).......... 1
184 1761400001 Lift Shaft.............................. . 1 217 1727233 Connector.............................. 4
185 1747509 Hydraulic Cylinder Assembly 218 1767745 Tube (Lift Valve A to
(Incl. Refs. 550 thru 560)......... . 1 Lift Cylinder, Piston End)......... 1
186 1752648 Hose (Lift Cylinder Piston End).. . . 1 219 1118554 Retaining Ring......................... 2
187 1185903 Elbow, 45°............................ . 2 220 1747512 Cylinder Rod Pin...................... . 1
188 1755198 Hose (Lift Cylinder Fixed End)..... . 1 221 1118808 Retaining Ring......................... 2
189 1721989 Connector.............. .............. . 1 249 1771429 Arm Assembly, Control (D).^........ 1
190 1747803001 Coupling Bracket..................... . 1 550 1729388 Hydraulic Cylinder Tube...... ...... 1
191 1863870 Coupling............................... . 2 551 1118735 Internal Retaining Ring............ . 1
192 1720733 Dust Plug............................... . 2 552 1185266 Oil Seal................................. 1
193 1180025 Retaining Ring........................ . 2 553 1186019 Back-Up Ring........ .................. 1
194 1767748 Tube (Lift Valve D to Aux. Out)... . 1 554 1177395 0-Ring........ .......................... 1
195 1767749 Tube (Lift Valve G to Aux. Out)... . 1 555 1724511 Cylinder Head.................. ....... . 1
196 1708012 Flat Washer, 3/4..................... . 1 556 1186018 Back-Up Ring.......................... . 3
197 1724703 Cylinder Anchor Pin................. . 1 557 1186017 0-Ring.................................. . 2
198 1113527 Retaining Ring........................ . 1 558 1747043 Hydraulic Cylinder Rod Assembly.. . 1
200 1755459 Control Lever......................... . 1 559 1186278 Pipe Plug....... ...... ................. . 1
201 1755460 Lift Lever.............................. . 1 560 1754414 Replacement Seal Kit (for Ref. 209).. N/l
202 1755473 Control Knob.......................... . 2 561 1767404 Control Arm (C)....................... . 2
N/l Item not included with the unit, order separately.
A/R As required.
