_____________ REPAIR PARTS — ALTERNATOR & PANEL
Drawing No. 92118
ITEM
PART NO.
QTY.
DESCRIPTION
1
75995
1
Lower Bearing Carrier
2
77005-Q
1
Rotor Assembly Q-550
80095-0
1
Rotor Assembly Q-700
3
87844-0
1
Stator Assembfy Q-550
87846-0
1
Stator Assembly Q-700
4
73159
1
Ball Beeiring
5
31971
1
Ball Bearing
, 6
72379
1
Upper Bearing Carrier
* 7
77006
4
Stator Stud
8
52858
8
M8-1.25 Flange Lock Nut
9
66386
1
Brush Holder
10
66849
2
M5-0.80x15mm
11
27756
4
Nylon Washer
12
86314
1
OeneratorTop Housing
13
75234
1
Resistor
14
22473
3
Flat Washer
15
22097
5
M6 Lock washer
16
74095
1
M6-1.00
X
60mm Capscrew
17
90141
2
Oround Cable
18
22447
1
Shakeproof Lock Washer
19
74906
4
M6-1.00
X
20mm Screw
20
92234
1
Controller Circuit Board
21
10-74260
1
Starter Cable
22
22129
2
5/16‘ Lock Washer
23
22259
2
S/16‘-18 Hex Nut
24
86316
1
Panel Sheet Metal
25
53650
1
4-pln Connector
26
91915
1
Connector
27
75244
1
Remote Harness
28
66476
2
M6-1.0
X
12mm Capscrew
with lock washer
29
56739
1
Starter Contactor
30
75476
3
M4-0.7
X
16mm Capscrew
31
22264
4
M4 Lock Washer
32
65795
1
Battery Charge Rectifier
33
90987
2
M3-0.5
X
15mm Capscrew
34
86317
1
Panel Support Bracket
35
75235
4
M5-0.8
X
30mm Capscrew
ITEM
PART NO.
QTY.
DESCRIPTION
36
82737
4
Vibration Mount
37
49813
4
M6 Hex Nut
38
49815
1
M5-0.8
X
16mm Capscrew
39
43182
2
M3 Lock Washer
41
53623
1
2.5A Circuit Breaker — Q-55Q
54502
1
3A Circuit Breaker — Q-70Q
42
67444
1
M5 Shakeproof Washer
43
83049
1
Voltage Regulator
44
49226
6
M5 Lock Washer
45
51716
4
M5-0.80 Hex Nut
46
90144
1
20A Circuit Breaker — Q-55Q
90145
1
30A Circuit Breaker -Q-70Q
47
90145
1
30A Circuit Breaker — all units
48
25105
4
No. 6-32 Screw w/lock washer
49
86315
1
Panel Cover
50
90734
4
M4-0.7
X
16mm Capscrew
and Flat Washer
51
22985
1
M4 ^t Washer
52
32300
1
Fuse Holder
53
22676
1
15 Amp Fuse
54
87798
1
Start/Stop Switch
55
92113
1
Fuel Pump Switch
56
75210-A
1
Termineil Block
57
23365
1
M4 Shakeproof Washer
58
51715
1
M4-0.7 Hex Nut
59
90156
1
Decal — Circuit Breaker Rating
20 Amp
60
90157
1
Decal — Circuit Breaker Rating
30 Amp
NOT USED ON THIS UNIT
61
89438-A
1
Customer Connection Decal
forQ-55Q
89438-B
1
Customer Connection Decal
forO-70Q
62
31791
1
Hose Clamp
63
23897
1
M5 Flat Washer
64
74908
1
M5
X
10mm Taptite Screw
65
23484-S
1
Bushing
66
75763
1
Battery Cable Boot
