________________REPAIR PARTS — BASE AND PULLEYS
Drawing No. 91390
rTEM
PART NO.
QTY.
DESCRIPTION
rTEM
PART NO.
QTY.
DESCRIPTION
1
86318
1
Mounting Base
44
74958
1
Cap and Dipstick Assembly
2
90141
1
Ground Cable
45
67871
1
0-ring Cap
3
46911
4
Rubber Mount
46
75712
1
O-ring Drain
4
25017
8
3/8*-16
X
1/2" Capscrew
47
75711
1
0-iing Adaptor
5
46526
10
Ml 0 Lock Washer
56
73179
1
Oil Filter Support
6
22129
2
M8 Lock Washer
57
70185
1
Oil Filter (FRAM PH #3614)
7
72391
2
Rubber Mount Skid
58
77667
1
Oil Pressure Switch
8
77603
2
51/6"-18x 3-1/2" Bolt
59
74948
3
5/16" Fitting
9
22259
2
5/16-18 Hex Nut
60
74950
1
Outer Oil Tube
10
52858
6
M8-1.25 Flanged Lock Nut
61
74951
1
Inner Oil Tube
11
51730
2
M8-1.25
X
60mm Capscrew
62
73134
1
Oil Pad Adaptor
12
29459
2
Belt Tension Spring
63
38750
3
M6-1.00
X
30mm Capscrew
13
75215
2
Spring Center Washer
64
74949
1
5/16" 90-degree Fitting
14
73146
4
Nylon Slide
65
68548
1
Oil Pad Gasket
15
75209
2
Nylon Slide Support
66
62684
1
Grounding Lug
16
73174
1
Exhaust Manifold
67
29289
—
1/16"
X 8'
Foam Tape
17
79678
2
Exhaust Manifold Gasket
69
75281
1
High Temperature Switch
18
55173
4
M8-1.25
X
20mm Capscrew
70
74027
2
M3-0.5 Pan Head Screw
19
72383
2
Collector Pan Gasket
71
43182
2
M3 Lock Washer
20
90859
1
Cover Plate - External
73
75237
4
Spring Retainer Washer
21
75224-B
1
Engine Pulley
74
77681
1
LOS 2-wlre Vinyl Cap
22
73106-B
1
Alternator Pulley
75
75474
1
17"
X
42"
X
2" Vinyl Cap
23
75216
1
40" Poly Vinyl 4L Belt
76
90800
1
Exhaust Elbow
24
49451
1
Pulley Retainer Washer
77
74907
1
1-1/8" Exhaust Clamp
25
42633
1
3/8"-24
X
1" Capscrew
78
75226
1
Air Cover
26
77017
1
Blower Housing Guide
79
56893
14
#10-24x1/2" Screw
27
73118
1
3/8"-24
X
2-1/2" Capscrew
80
75229
1
Slide Pan Gasket
28
74906
5
M6-1.00
X
20mm Screw
81
75227
1
Slide Pan
29
91123
1
Fuel Pump Bracket
82
79246
8
M6-1.0
X
16mm Capscrew
30
72375
1
Blower Housing
with lock washer
31
73185
1
Blower Housing Spacer
83
22473
4
M6 Flat Washer
32
22097
6
M6 Lock Washer
85
72384-C
1
Exhaust Outlet Cover
33
77682
1
M5-0.8
X
80mm Capscrew
87
77643
2
Exhaust Outlet Gasket
34
75242
4
Generator Mounting Spring
88
86136
1
Sound Barrier Pad
35
49813
2
M6-1.00 Hex Nut
90
22447
1
M6 Toothed Lock Washer
36
45757
2
M6-1.0
X
25mm Capscrew
91
90088
1
Vinyl Coated Clamp
37
90475
1
Fuel Pump
92
74908
10
M5-0.8
X
10mm Screw
38
87769
1
Fuel Filter
93
81105
2
5/16’-18 Flange Nut (special)
39
87768
1
1/8" Pipe to 1/4" Tube Fitting
94
23897
6
M5 Flat Washer
40
87770
1
Fuel Line
95
67210
1
Decal - Ground
42
26925
1
a/8" NPT Oil Drain
96
45756
9
M6
X
10mm Taptlte Screw
43
75710-A
1
Oil Fill and Drain Tube
97
22131
1
Ml0 Flat Washer
- 2 1 -
