DECALS
REPAIR PARTS
KEY
NO.
1
2
3
4
5
6
7
8
11
13
15
16
PART
NO.
158167
145005
158037
158169
158172
157140
101892X
158038
158176
158168
136832
158166
DESCRIPTION
Decal,
Decal
Decal
Decal,
Decal,
Decal,
Decal
Decal
Decal,
Decal
Decal
Decal
Fender St Lawn Tret
Bat Dan/Poi P/L Symbols
Hood RH
Deck
Engine
Danger Fender(E/F)
Clutch/Brk (E/F)
Hood LH
Seat Replacement
Wheel Steering
V-Belt Schematk
Fender
WHEELS & TIRES
4 , 1 0
3 , 9
11
KEY
PART
NO,
NO.
DESCRIPTION
19
156993
Decal, Saddle Oper. Inst. Hyd, E/F
138311
Decal Handle LiR Height Adz
142341
Decal Drawbar Cntl. Mut Hyd
157257
Manual Owner"s (Eng)
159414
Manual Owner's (Fr)
Available accessories (not included with tractor):
C42
Grass Catcher
LSB42
42" Snow Blower
LC05
Wheel Weights
LBD48
48" Snow Blade
LA018
Tire Chains
MK42
Mulching Kit w/Biades
KEY
PART
NO.
NO.
DESCRIPTION
1
59192
Cap Valve Tire
2
65139
£1ten, Valve
3
106222X
Tire F Ts 15 X 6 0 “ 6 Service
4
59904
Tube Front (Service Item Only)
5
106732X427
Rim Asm 6" (Front White Service)
6
278H
Fitting Grease (Front Wheel Only)
7
9040H
Beanng Flange (Front Wheel Only)
8
106108X427
Rim Asm 8" (Rear White Service)
9
106268X
Tire R Ts 18x9 5-8 C Semice
10
7152J
Tube Rear (Service Item.Only)
11
104757X
Cap Axle BIk 1 50 X 1 00
144334
Sealant, Tire ¡10 oz. Tube)
NOTE; AH component dimensions given in U,S mene;
1 inch := 25,-I mm
