A
uger
/I
mpeller
Models 938001,002,003,004,006,007,008,009,301,301 *,302,303
Item No.
Part No.
Qty.
Description
1
08329900
1
Spring-Tension (002,004,302)
2
53800400
1
Deflector-Discharge Chute Assembly
3
06527600
23
Nut-Locking-Center-Flange .250-20 (001,003,301)
4
06437800
2
Washer-Flat-Rubber .31 x 1.25 x .06
5
03801900
1
Chute-Discharge
6
06204200
8
Bolt-Round Head Square Neck .25-20 x .75
7
03805600
1
Handle (002,004,302)
03801800
1
Handle (001,003,006,007,008,009,301,301 *,303)
8
07409500
4
Screw-Tapping 8-18 x 1.50
9
05514500
1
Bushing-Flange .325 x .444 x .440 x .560 (002,004,007,009,302)
10
08329800
1
Spring-Compression .045 x .360 x 2.75 (001,003,006,008,301,301 *,303)
11
05429800
1
Ball .375 (001,003,006,008,301,301 *,303)
12
03801700
1
Bracket-Discharge Chute Rotation
13
53800800
1
Support-Bearing (001,002,003,004,301,302)
03807100
1
Support-Bearing-Left Hand (006,007,008,009,301 *,303)
14
03803200
1
Deflector-Exhaust (001,003,006,008,301,301 *)
15
03808000
1
Tape-Adhesive Backed Foam 11.0
16
07401500
6
Screw-Tapping .250-20 x .37
17
03804000
1
Gear-Discharge Chute Segment
18
03804100
1
Pinion-Discharge Chute 18T (002,004,007,009,302)
19
06114300
5
Screw-Machine .25-20 x .50
20
03800800
2
Cup-Bearing
21
05418800
2
Bearing Ball .699 x 1.575 x .47
22
06203700
1
Bolt-Round Head Square Neck .25-20 x 1.00
23
03800300
1
Chassis
24
03802300
1
Axle
25
06404300
4
Washer-Flat-Steel .406 x .812 x .065
26
07139400
2
Tire/Wheel Assembly 7.0 x 1.5
27
05717400
2
Ring-Retaining-External .375 x .035
28
03802400
2
Cap-Hub
29
03802500
1
Scraper
30
53800800
1
Support-Bearing (001,002,003,004,301,302)
03807200
1
Support-Bearing-Right Hand (006,007,008,009,301 *,303)
31
53800300
1
Housing-Impeller Assembly
32
05706100
1
Ring-Retaining-External .672 x .035
33
03803000
6
Plate-Bolt-Self-Tapping
34
03807000
2
Impeller Half
35
53800700
1
(A) Kit-Impeller Replacement (001,002,003,004,301,302)
03806900
1
(B) Shaft-Impeller-See Note (006,007,008,009,301 *,303)
36
06426600
12
Washer-Flat-Steel .281 x 1.000 x .063
37
07412400
12
Screw-Tapping .250-20 x 1.00
38
06114400
10
Screw-Machine .25-20 x .75
39
05809200
6
(B) Pin-Roll .250
X
1.75 - See Note (006,007,008,009,301 *,303)
40
03806200
1
Arm-Spring (001,002,003,004,301,302)
03807400
1
Bracket-Spring (006,007,008,009,301 *,303)
"A" or "B' in front of the description in the description column has the
following meaning: A=Before serial numbers as follows and B=After
serial numbers as follows:
938001 = 002777 938003 = 000899 938301 = 000250
938002 = 001956 938004 = 000801 938302 = 000250
Ariens» Sno-Thro 938 Rev. S/98
