E

ngine

and

D

rive

Models 938001.002,003,004,006,007.008.009.301,301 *,302,303

Item No.

Part No.

Qty.

Description

1

07525300

1

Cap-Fuel

2

03800400

1

Tank-Fuel

3

03807800

1

Tape Foam-Neoprene 6.0"

4

04003500

1

Tie Wrap-15.25"

X

120 lbs (002,004,302)

5

02917200

2

Hose Clamp

6

03328000

1

Gas Line Hose (001,003,006,008,301,301*)

03807900

1

Gas Line 1/4" I.D. x 9.5 (002,004,007,009,302,303)

7

06527600

6

Nut-Locking-Center-Flange .250-20

8

03803300

1

Line-Primer

9

06204200

4

Bolt-Round Head Square Neck .25-20 x .75

10

03802600

1

Bracket-Fuel Tank Mounting

11

03807500

1

Arm-Idler

12

03801100

2

Pulley-Drive 3L x 1.52 Diameter (001,003,006,008,301,301*)

03801200

2

Pulley-Drive 3L x 1.80 Diameter (002,004,007,009,302,303)

13

06409000

4

Washer-Flat-Steel .328 x .875 x .062

14

06303600

6

Washer-Lock .313 x .078

15

05905300

2

Bolt-Hex .31-24

X.

75

16

08331600

1

Spring-Tension .043 x .44 x 3.31

17

07228500

1

V-Belt 3L-Section 33.00 x .38 (001,003,301)

07228600

1

V-Belt 3L-Section 33.45 x .38 (002,004,302)

07232100

1

V-Belt 3L-Sectlon 33.00 x .38 (006,008,301*)

07232200

1

V-Belt 3L-Section 33.49 x .38 (007,009,303)

18

06200100

1

Bolt-Round Head Square Neck .25-20 x 1.25

19

07321900

1

Idler-Flat 1.75

X.

27

20

06426600

1

Washer-Flat-Steel .281 x 1.000 x .063

21

03801000

1

Pulley-Impeller Shaft 3L x 6.0 Diameter

22

06606100

1

Key-Square .188 x .75 x .188

23

05902200

2

Bolt-Hex .31-18

X

.75 (001,003,006,008,301,301*)

3

Bolt-Hex .31-18

X

.75 (002,004,007,009,302,303)

24

03805500

2

Finger-Belt (001,003,006,009,301,301 *)

1

Finger-Belt (002,004,007,009,302,303)

25

05900300

2

Bolt-Hex .31-18

X

1.00 (001,003,006,008,301,301*)

1

Bolt-Hex .31-18

X

1.00 (002,004,007,009,302,303)

26

06114400

1

Screw-Machine .25-20 x .75

27

06403800

2

Washer-Flat-Steel .505 x .875 x .024

28

05513400

1

Bushing-Flange .265 x .437 x .250 x .750

29

03803400

1

Motor-Starting Tec #1133-106 (003,008)

03803500

1

Motor-Starting Tec #1A173-111 (004,009)

30

07029600

2

Screw-Hex Flange Washer Head-TX .25-20 x .868 (003,008)

07029500

3

Screw-Hex Flange Washer-Head-TX-Sems .25-20 x .49 (004,009)

31

08243800

1

Engine-Tec 3 HP 2 Cycle (001,003,006,008,301,301*)

08243900

1

Engine-Tec 5 HP 2 Cycle (002,004,007,009,302,303)

32

06504200

2

Nut-Locking .312-18

33

03801600

1

Bracket-Engine Mounting

34

06114600

2

Screw-Machine 8-32 x 2.75 (003,004,008,009)

35

06406800

2

Washer-Flat-Steel .194 x .492 x .047 (003,004,008,009)

36

06531300

2

Nut-Locking 8-32 (003,004,008,009)

Anens» Sno-Thro 938 Rev. 6/98
