H
andlebars
, C
ontrols
,
and
S
hrouds
Models 938001,002,003,004,006,007.008,009,301,301 *,302,303
Item No.
Part No.
Qty.
Description
1
07008200
2
Nut-Push .312 (001,002,003,004,301,302)
2
03806351
1
Engine Bail (001,002,003,004,301,302)
03807351
1
Bail-LCIutch Control (006,007,008,009,301*,303)
3
07524800
1
Extension Cord Tec #1A174-17 (003,004,008,009)
4
03804400
1
Handle Bar-Upper
5
05514500
2
Bushing-Flange .325 x .444 x .440 x .560
6
06412300
2
Washer-Flat-Steel .344 x .688 x .065
7
05934100
1
Bolt-Hex .25-20
X
1.38 (002,004,302)
8
07525600
2
Knob (002,004,302)
9
06527600
6
Nut-Locking-Center-Flange .250-20
10
03804900
1
Lever-Chute DefI Control (002,004,302)
11
03232200
1
Spacer .230
X
.310
X
.255 (002,004,302)
12
07404500
1
Screw-Tapping 12-24 x .50 (002,004,302)
13
03804800
1
Anchor-Cable-Chute DefI Control (002,004,302)
14
06218000
1
Bolt-Round Head Square Neck .38-16 x 2.25 (002,004,302)
15
06209400
1
Bolt-Round Head Square Neck .25-20 x 1.25 (002,004,302)
16
03215500
1
Friction Plate (002,004,302)
17
03804600
1
Housing-Inner-Chute DefI Control (002,004,302)
18
03804700
1
Housing-Outer-Chute DefI Control (002,004,302)
19
01123800
2
Friction Washer (002,004,302)
20
08320900
1
Spring-Compression .187 x .56 x 1.62 (002,004,302)
21
06409600
1
Washer-Flat-Steel .458 x .750 x .06 (002,004,302)
22
06512200
1
Nut-Locking Top .375-16 (002,004,302)
23
06929000
1
Control-Choke (001,003,006,008,301,301*)
06937300
1
Control-Choke 5 HP (002,004,007,009,303)
24
01157100
1
Recoil Start Handle
25
03802900
1
Bracket-Starter-Handle
26
06206000
1
Bolt-Round Head Square Neck .25-20 x 1.50
27
07514500
1
Knob (002,004,007,009,302)
28
53800100
1
Crank-Chute (002,004,007,009,302)
03802800
1
Support-Chute Crank (002,004,007,009,302)
05800200
2
Pin-Roll .125
X
1.38 (002,004,007,009,302)
06406200
2
Washer-Flat-Steel .754 x 1.125 x .062 (002,004,007,009,302)
08330600
2
Spring-Compression (002,004,007,009,302)
03805300
2
Sleeve-Spring Thrust (002,004,007,009,302)
03805400
2
Washer-Friction .53 x 1.00 x .094 (002,004,007,009,302)
29
03803900
1
Spacer-Crank Transfer Pinion (002,004,007,009,302)
30
06701100
1
Pin-Cotter .15
X
1.25 (002,004,007,009,302)
31
03804300
1
Pinion-Crank Transfer 48T (002,004,007,009,302)
32
03804200
1
Gear-Crank Transfer 12T (002,004,007,009,302)
33
03803600
1
Shaft-Chute Crank Transfer (002,004,007,009,302)
34
06701000
1
Pin-Hair Internal .08 x .38 x 1.42 (002,004,007,009,302)
35
06406800
2
Washer-Flat-Steel .194 x .492 x .047
36
06504200
2
Nut-Locking .312-18
37
07524500
2
Knob
38
06409000
4
Washer-Flat-Steel .328 x .875 x .062
39
06303600
2
Washer-Lock .313 x .078
40
03802100
1
Handle Bar-Lower
41
03802700
2
JBolt .31-18
42
02460700
1
Key-w/Cap
Ariens» Sno-Thro 938 Rev. 6/98
