PARTS LIST FOR MODEL 214-100A
REF.
NO.
PART
NO.
COLOR
CODE DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE DESCRIPTION
NEW
PART
1 4103—474 Engine Bed 23 4138—474 Inner Tine Adapter Ass'y.
2 4126 Inspection Plate 24 712-116 Hex Ins. L-Nut %-24 Thd.
3 710-128 Hex F-Tapp Scr. #10-32 x .50'! 25 4134—474 Outer Tine Adapter Ass'y.
Lg. 1 26 710-191 Hex Scr. %-24 x 1.25" Lg.*
5 710-259 Hex Sems Scr. 5/16-18x1.00' ( 27 742-106 Tine 12"—Right Hand
Lg.* 28 742-105 Tine 12"—Left Hand
6 —
Engine 29 736-169 L-Wash %" Scr.*
7 710-158 Hex Scr. 5/16-24 x 1.25" Lg.* 30 712-241 Hex Nut %-24 Thd.*
8 714-122 Sq. Key 3/16X.75" Lg.* 31 736-169 L-Wash. %" Scr.*
9 756-107 Sheave 2 I/ 2 " O.D. 32 712-798 Hex Nut %-16 Thd.*
10 710-765 Set Scr. 5/16-24 x .25" Lg 33 736-169 L-Wash. %" Scr.*
11 736-119 L-Wash. 5/16" Scr.* 34 712-798 Hex Nut %-16 Thd.*
12 712-123 Hex Nut 5/16-24" Thd.* 35 710-459 Hex Scr. %-24 x 1.50" Lg. H.T.
13 4198 Lower Control Rod 36 714-126 #9 Hi-Pro Key 3/ 16 X %" Dia.
14 712-107 Hex Cent. L-Nut 14-20 Thd. 37 716-119 Snap Ring %" Dia. Shaft
15 4195 Belt Clip 38 756-196 Pulley 4.50" O.D.
16 712-116 Hex Ins. L-Nut %-24 Thd. 39 736-231 FI-Wash. .344" I.D. x 1.25" O.D.
17 4563 Belt Clip 40 736-119 L-Wash. 5/16" Scr.*
18 756-199 Flat Idler 41 710-118 Hex Scr. 5/16-18 X .75" Lg.*
19 4105—474 Mounting Plate Ass'y. 42 754-103 V-Belt '/2 X 27" Lg.
20 4187 Idler Bracket Ass'y. 43 732-233 Tension Spring
21 721-120 Foam Seal 1.25" I.D. x2.12" 44 712-107 Hex Center L-Nut ’^-20 Thd.
O.D. 45 4161 Belt Guard
22 721-121 Foam Seal 2.25" I.D. x 2.94" 46 738-183 Shoulder Scr. .500 Dia. x.215
O.D.
* For faster service, obtain standard nuts, bolts, and washers locally. If these items cannot be obtained locally, order
by part number and size as shown on parts list.
(474—Citrus) When ordering parts if color or finish is important, use the appropriate color code shown at left.
(e.g. Citrus—4624 (474)).
Find us fost in ths
The engine is not under warranty by the tiller manufacturer. If repairs or service is
needed on the engine, please contact your nearest authorized engine service outlet. Check
the “Yellow Pages” of your telephone book under “Engines-Gasoline.”
