PART НО. OESCRIPTIOH PART HO. OESCRIPTIOH
1 544262-101 Presser Regulating Thua Screv 39 370243 Heedle Bar Crank Rod Comp.
2 410355 Presser Bar Spring
3 544204-001 Presser Bar Guide BiackeL Sci ev
■1 410352 Presser Bar Guide Bracket Сошр. 42 511030 Heedle Bar Crank Rod Slide Block
5 412787-100 Presser Bar Lifter 43 543801-006 Heedle Bar Crank Rod Slide Block Pin Retaining
6 544441 Presser Bar Lifter Screw Stud 44 370242 Heedle Bar Crank Rod Comp.
7 410351 Presser Bar 45 410329 Heedle Bar Eccentric Cam Comp.
8 504063-451 Presser Foot Screw 46 544204-002 Heedle Bar Eccentric Cam Set Screw(2)
9 412731 Presser Foot Comp. 47 410340 Heedle Bar Crank Rod Pin
10 410349 Tliread Cutter 48 543801-006 Heedle Bar Crank Rod Pin Retaining Ring
11 410348 Presser Foot Spring 49 376516 ' Striker
12 544264 Presser Foot Screw Stud 50 544211-051 Striker Screw
13 410322-100 Heedle Bar Bushing (upper) C^p 51 376515 Heedle Bar Connecting Link Comp.
14 410323 Needle Bar Bushing (upper)
15 544204-001 Needle Bar Bushing Set Screw (2) 53 376567 I’resser Bur Felt
16 376844 Heedle Bar 54 376514 Needle Clamp Thread Guide
17 376554 Heedle Claap
18 376848 Heedle Bar Thread Guide
19 544211-059 Heedle Bar Thread Guide Set Screw
20 374102 Heedle Bar Set Screw
21 334364 Heedle Set Screw (2)
23 410324 Heedle Bar Bushing (lower)
24 N2054 42 14 Heedle («14)(2)
25 412684 An Shaft
26 410279 Arm Shaft Bushing (2)
27 544204-001 Ara Shaft Bushing Set Screw(2)
28 543801-007 An Shaft Retaining Ring
30 410325 Heedle Bar Connecting Stud Comp.
31 544044 Heedle Bar Connecting Stud Screw
32 410340 Heedle Bar Connecting Link Pin
33 543801-006 Heedle Bar Connecting Link Pin Retaining Ring
34 410327 Heedle Bar Connecting Link
35 412707 Heedle Bar Crank Comp.
36 544203-001 Heedle Bar Crank Rod Pin Screw
37 544204-001 Heedle Bar Crank Screw(2)
38 544203-001 Heedle Bar Connecting Link Pin Screw
