PART HO. DI.SCRIPTIOH
1 419087 Swi tch. Transfor mer, l..aap Holder Comp.
2 549324 Transformer Screw(2)
3 543805-002 Transformer Spi ing Vaslier(2)
4 412752 Transformer Br acket
5 544212-001 Transformer Bracket Screw(2)
6 544212-001 Lamp Holder Bracket Screw(2)
8 419088 Lamp
10 419114 002 Motor Comp, (for U17CSA)
12 544259 Motor Bracket Clamping Screw
13 543805-005 Motor Bracket Clamping Screw Vasher
14 410252 Rotating Shaft Bushing (left)
17 410470 Rotating Shaft Collar Comp.
18 544204-001 Rotating Shaft Collar Set Screw(2)
19 408730 Rotating Shaft Thrust Vasher(2)
20 410253 Rotating Shaft Bushing (right)
21 544204-001 Rotating Shaft Bushing (right) Set Screw
22 410257 Rotating Shaft
23 410469 Rotating Shaft Collar (fixed)
,24 543808-004 Rotating Shaft Collar Positioning Pin
25 543809-D04 Rotating Shaft Spring Pin
26 410256
Rotating Shaft Comp.
27 410268-002 Pulley
28 543848
Pulley Set Screw Washer
29 544270-001 Pulley Set Screw
30 412721 Motor Belt
31 419451 001 Controller Comp, (for UL/CSA)
32 542766-001 Cord Holder
33 544212-001 Cord Holder Scr ew
34 412737 Cord Clamping Plate
35 544212-001 Cord Clamping Plate Screw
36 544212-001 Switch Bracket Screw(2)
37 419115 Electrical Data Plate (for UL/CSA)
. ::
PART HO. DESCRIPTION
