List of Parts for 1000 Machine
DS. No. Part No. Description
1 502500-451 Bed (Convertible) Lid with Bed Leg (back) cpI. 502198-451,502328, 514560-451, 502353, 502200
507309, 502201 and 502203-451
2 502198-451 Bed (Convertible) Lid cpI. 502470, 514556-451
3 502470-000 Bed (Convertible) Lid Stud cpI.
4 514556-451 Bed (Convertible) Lid Set Screw
5 502200-000 Bed (Convertible) Lid Bracket Stud
6 502201-000 Bed (Convertible) Lid Bracket Compression Spring
7 507309-000 Bed (Convertible) Lid Bracket Retaining Ring
8 502328-000 Bed (Convertible) Lid Bracket
9 502203-451 Bed Leg (back) cpI.
10 506499-000 Bed Leg (back) Locating Pin
11 502353-000 Bed (Convertible) Lid Bracket Washer
12 514560-451 Bed (Convertible) Lid Bracket Screw
13 514629-451 Bed Leg (back) Screw (2x)
14 502472-451 Convertible Bed Leg Cover cpI. with Capacitor Unit 502329-451, 503251-000
15 503251-000 Capacitor with Harness cpI.
16 503252-000 Capacitor
17 502329-451 Convertible Bed Leg Cover
18 514670-451 Convertible Bed Leg Cover Screw (2x)
19 172203-000 Bed Leg (back) Cushion
20 514520-805 Bed Leg (back) Cushion Screw
21 502452-451 Arm Top Cover cpI. 502453-451,503320. 502455, 502469, 514648
22 502469-000 Arm Top Cover Guide Plate
23 502455-000 Arm Top Cover Spring
24 514648-451 Arm Top Cover Screw (2x)
25 503320-000 Arm Top Cover Stabilizer Insulating Strip
26 502420-451 Arm Spool Pin col.
27 507139-452 Arm Spool Pin
28 ~^503336-451 Arm Spool Pin Cushion
29 514675-451 Arm Spool Pin Screw (2x)
JO--------- -----1-82238-451 AmilQB Cover Lid Thread Guide
31 514675-451 Arm Top Cover Lid Thread Guicie Screw
32 502418-451 Face Plate cpI.
33 514509-830 Face Plate Screw (2x)
34 514655-451 Face Plate Mounting Screw (2x)
35 503324-451 Bed (Convertible) Lid Spacer
36 503328-451 Arm Si Bed (Painted and Ornamented)
37 503285-451 Override Dial Panel cpI. 604824-451, 503284
38 503284-000 Override Dial Panel Soring
39 604824-000 Overnde Dial Panel
40 502445-451 Bed Cover Plate (right end)
41 511254-000 Bed Cover Plate (right ena) Spring (2xj
42 511233-451 Bed Plug (Front, Plastic)
43 172203-000 Bed Cushion (2x)
44 140809-805 Bed Cushion Screw (2x)
45 502442-451 Bed Cover Plate (Bottom) cpl.
46 514670-451 Bed Cover Plate (Bottom) Screw (2x)
47 511077-000 Slide Plate Spring
48 514515-451 Slide Plate Soring Screw
49 506433-000 See-thru Slide Plate cpl.
50 502323-451 Bed Cover (Convertible) cpl. 502326-451, 172203, 514520-805. 500783
51 502326-451 Bed Cover (Convertible)
52 _ 500783-000 . Bed Cover (Convertible) Cushion Screw Nut
53 172003-000 Bed Cover (Convertible) Cushion
54 514520-805 Bed Cover (Convertible) Cushion Screw
55 500277-819 Bed Cover (Convertible) Screw
