SINGER XL-1000 - Manual (Page 11)

List of Parts for 1000 Machine
Pos. No. Part No. Description
1 312270-000 Needle Bar Driving Arm Extension Retaining Spring
2 503345-000 Needle Bar Vibrating Bracket with Needle Bar Dnving Arm cpl.
502335. 503319, 502384, 502356, 506343, 514650-451,502387, 155577, 514635-451
3 502384-000 Needle Bar Driving Arm cpl.
4 502387-000 Needle Bar Driving Arm Positioning Stud
5 155577-000 Needle Bar Driving Arm Positioning Stud Washer
6 514635-451 Needle Bar Driving Arm Positioning Stud Screw
7 514650-451 Needle Bar Driving Arm Ball Joint Set Screw
8 506343-000 Needle Bar Driving Arm Bali Joint Washer
9 502356-000 Needle Bar Driving Arm Bail Joint
10 503319-000 Needle Bar Driving Arm Ball Joint Spring
11 502335-000 Needle Bar Driving Braoket cpl.
12 503283-000 Bight Drive Linear Motor with Bracket, Safety Solenoid and Harness cpi. 502382, 619696
13 619606-000 Bight Drive Linear Motor Safety Solenoid Harness cpl.
14 502382-000 Bight Drive Linear Motor with Bracket and Safety Solenoid cpl.
503318, 312216, 619614, 514648-451,382639, 514676-451
15 382639-000 Needle Bar Driving Arm Positioning Lever
16 514676-451 Needle Bar Driving Arm Positioning Lever Screw (2x)
17 312216-000 Bight Drive Linear Motor with Bight Driving Arm 312193
18 514648-451 Bight Drive Linear Motor Mounting Screw (2x)
19 619414-000 Bight Drive Linear Motor Harness (Extension)
20 503318-000 Bight Drive Linear Motor Bracket with Safety Solenoid cpl. 503383, 503372, 514671-451
21 502383-000 Bight Dnve Linear Motor Bracket
22 514671-451 Needle Bar Driving Arm Safety Solenoid Screw
23 503372-000 Needle Bar Driving Arm Safety Solenoid
24 514560-451 Bight Drive Linear Motor Bracket Screw (front)
25 514680-451 Bight Drive Linear Motor Bracket Screw (back)
