INSTRUCTIONS FOR ORDERING
In ordering fi'om tliis list, use ONLY the part NUMBER
in the FlllS'r column.
Tlie nuinher slam])eil on a Sewing Machine Part is in every
case the nuinher of the single part only.
Every combination of parts sent out a.s such has its specific
number, which, although not stamped on the parts, must be
used when ordering the combination.
Each number always indicates the SAME PART in whatever
list it appears, or for whatever machine.
The letters after some of the numbers indicate the stylo of
finish only, as follows:
A—Hardened, Polished, Nickel Plated mid Buffed
B—Polished, Nickel Plated and Buffed
C—Hardened Only
D—Polished Only
E—Soft, Not Pohsheil
E—Hardened and Polished
H-^BIued
J—Nickel Plated Only
K—Hardened and Nickel Plated
L—Brass Plateil
M—Oxidizial
N—.Japanned, Dull
P—.Japanned, Bright
R—Merlized
T—Copper Plated
'r. A.—Hardened, I’olished, Copper and Nickel Plated
and Buffed
B.—Cop|)ci' and Nickel I’lafed and I’olished
T. J.—Co|iper and Nickel Plated Only
T. Iv.—Hardened, Copper and Nickel Plated
T. M.— Copper Idatcd and Oxidized
T, L—Copper and Brass Plated
U —Zinc Plated
V—Silver Plated
VV—I’olisheil and Nickel I'lated
V-.-Black Nickel I'lated Only
Z—Chromium Plated
Z. B.—Polished, Nickel Plated, Buffed and Chromium Plated
Z. J.—Nickel and Chromium Plated
These letters MUST BE USED when they appear in the list;
and AFTER the number as in the list.
In this series;
1 to l.aOO and .50001 to .51500 are Screw Numbers
1501 to 1800 and 51,501 to 51800 are Nut Numbers
1801 to 2t)00 and 51801 to 52000 are Roller Numbers
2001 to 50000 ami 52001 and upward are nvmdjers of
Machine Parts
The figures in the second column refer only to the plates,
illustrating the jiarts, and are NOT TO BE USED in ordering.
Parts marked with an asterisk (*) are furnished only when
repairs are made .at factor}'.
LIST OF PARTS COMPLETE
FOR
E9!i20,
MACHINE No. 147-50
FOR GENERAL WORK IN LIGHT WEIGHT FABRICS. ONE
NEEDLE, ONE LOOPER. SHORT NEEDLE BAR AND
LDOPER STROKE. THE LOOPER IS ARRANGED $0 THAT IT
MAY BE THROWN OUT OF POSITION FOR CONVENIENCE
IN THREADING. AN IMPROVED OILING SYSTEM AUTO­
MATICALLY OILS ALL OF THE PRINCIPAL BEARINGS OF
THE MACHINE. BALANCE WHEEL N0.64259. DIAMETER
OF BELT GROOVE 2 INCHES. SPEED UP TO 4300.
No. Vl.ATK N.\MK
*58127 ,\rm, upper and lower (solid) with 948n,
154(14, 5848:i, two 1540.5 and four
111 1022......................................................
t)S12,S 9!I17 .\rni Bottom Cover...........................................
tlS 129 9917 “ “ “ Gasket (cork)........................................
111.5710 20,50:i “ “ “ Screw....................................................
t)S;!,50 !)i)22 “ Oil Cup, for oiling .\rin Rock Shaft
Front Bearing..............................................
tiSlIiO 9922 .Arm Oil Cup, for filling oil reservoir. . .
.51548 9922 “ “ Oil Pad (braided cotton)
1,‘i 129:1 “ Rock Shaft.................................................
i:ii29i — “ “ “ i:il29;i with I2:15 k and
131295.........................................................
