SINGER 114-39 - Manual (Page 11)

20
FOOT LIFTER PARTS
No. Plate
17876 23159
17877 23159
17878 23159
17879 23159
161E 23159
17880
17881 23159
443C 23159
17882 23159
17883 23159
17884 23159
17885
Name
Treadle with 443C.......................................................
“ Pitman Rod (lower)...........................................
“
« • (upper)..................................
" « « Clamp with two 161E..
" If o II Screw..........................
Treadle Pitman complete. Nos. 17877 to
17879....................................................................
Treadle Shaft................................................................
" " Set Screw.............................................
" Spring...........................................................
" stand.............................................................
Treadle complete. Nos. 17876, 17881 to
17883 and two wood screws 1 In. No.
10 ........................................................
Treadle and Pitman complete. Nos. 17880
and 17884.............................................................
STARTING LEVER
No. Plate Name
13351 23159 Chain, 46 In. to 55 in. long. with 56864
and 56865.......................
Note : When ordering No. 13351, give length required.
56864 23159 Chain Hook (large)................
56865 23159 " " (small)..........................
17876 23159 Treadle with 443C..................
17881
443C
23159 " Shaft..............................
23159 * " Set Screw..................................
17882 23159 ” Spring............................
17883 23159 " Stand.............................
17884 23159 Treadle complete. Nos. 17876, 17881 to
17883 and two wood
1 0 .................................
screws 1 In. No.
21
TABLE BELT GUIDE
No. Plate Name
39218 23159 Belt Guide with two 168E.....................................................
168E 23159 " " Set Screw....................................................
17892 23159 Braclcet with two 153E.........................................................
17893 23159 Pulley......................................................................................
39219 23159 " Shaft (long) with 17896 and 63973
63973 23159 » 1 1 « (braided cotton)
39220 23159 " " (short) With 17896 and 63974
63974 23159 n » » yidj (braided cotton)
17896 23159 " ■ Plug..............................................
153E 23159 " " S e t Screw..........................................
39221 23159 Table Belt Guide complete. Nos. 17892,
39219, 39220, two each 17893, 39218
and three wood screws 1 1/4 In. No.
12 ............................................................
THREAD UNWINDER
FOR ONE LARGE SPOOL OR ONE LARGE CONE OF THREAD
No. Plate Name
225259 23160 Spool Rest with 201018C..............................................
150203 23160 " ■ Cushion (felt).............................................
225388 23160 " ' Rod..............................................................
200383G 23160 « » * 3 gt Screw.............. ........................
201018C 23160 • " Set Screw...................................................
202490 23160 " Stand with 200383C............................................
225391 23160 Thread Guide.............. .........................................................
60771 23160 " Guide..................................................................
60772 .......... " " 60771 with 41635.............................
41635 23160 *' " Braclcet with 175E...............................
175E 23160 « . 1 1 9 0 t Screw...........
201696J 23160 " “ Lock Nut............................................
225326 23160 • " Position Cup.................................
225324 23160 “ " Rod with 208E and 225322...
208E 23160 ... Screw..................................................................
225322 23160 « . » Washer........................................
225260 ------- Thread Unwinder complete. Nos. 150203,
201696J,202490,225259,225324,225326,
225388, 225391 and three wood screws
7/8 In. No. 12........................................................
27739 23160 Thread Cone (wood) for large cones...........................
225390 23160 " ' Holder, for Inverted cones..
Note; Nos. 27739 and 225390 are used with, but not
Included In 225260.
60773 23160 Thread Unwinder with Thread Guide com­
plete, Nos. 60772 and 225260.............................
