PARTS FOR MACHINE No. 147-80
PARTS FOR MACHINE No. 147-80
No. Plate
50396F 20704
131394 20704
389F 20704
50473F. 20704
13147] ), 20696
131484
896AL 20696
1057AL 20696
68460 20706
68461 20706
330D 20706
131395 20706
29234 20706
10БЗЕ 20706
51224W 20706
131729 20702
131730 20702
190J 20702
22436 20702
131731
131197 20702
59343 20702
735AL 20702
134258 20702
134259 20702
68495 20702
134260 20702
68467 20702
207E 20702
131500 20696
131502
896AL 20696
1057AL 20696
68497 20696
134260 20696
54177 20707
131544 20708
131545 20708
Name
Cloth Plate Screw (right)............
'' '' Thread Guard..............
" " " " Screw (lower)..
" " ” и ri (upper)..
Crank Connecting Rod with two each 896AL
and 1057AL.......................
Crank Connecting Rod 131471 with 131343.
" " " Cap (lower) Screw
(2)..............................
Crank Connecting Rod Cap (upper) Screw
(2)..............................
Face Plate (lower half)..............
" " " " Gasket (cork)...
“ " " " Screw (2)......
" " (upper half)................
" " « « Position Plate..
I t I I I I I I I I I I
Screw............................
Face Plate (upper half) Thumb Screw..
Feed Bar.............................
" " Feed Dog Seat (adjustable) with
460AL............................
Feed Bar Feed Dog Seat Screw.........
" .............. . '' Washer.......
Feed Bar with Feed Dog Leveling Device
complete, Nos. 190J, 22436, 68467,
131729, 131730 and two 207E......
Feed Bar Hinge Pin (eccentric).......
" " " " Collar with 735AL___
" " " " " Set Screw......
" " Slide Block.................
" " " “ 134258 with 68495 and
134260...........................
Feed Bar Slide Block Oil Pad (wick)...
" " “ " " " Retainer...
" " Wearing Plate................
“ " ” '' Screw (2).......
Feed Connecting Rod with 1057AL, 68497,
134260 and two 896AL.............
Feed Connecting Rod 131500 with 54025...
'' " " Cap Screw (2).....
" " " Clamping Screw.....
" " " on Pad (wick).....
« H H I I I I * . « . ___ Retainer....
" Dog, 16 teeth (16 teeth to the
Inch) for 38486..................
Feed Dog,13 teeth (12 teeth to the Inch)
for 46059........................
Feed Dog,17 teeth (16 teeth to the Inch)
for 46059........................
No. Plate Name
50073J 20707 Feed Dog Screw, when stationary Needle
Guard Is used.....................
140275J 20707 Feed Dog Screw, when movable Needle
Guard Is used.....................
460AL 20702 Feed Dog Stop Screw...................
5106lAL 20696 ” Eccentric Body Set Screw (3).....
7071 20696 '' ' Clamping Washer (2)............
217J 20696 " " " " Screw (2)
54025 20696 Feed Eccentric (adjustable) with 1103C,
two each 217J,7071 and three 51061AL
1103C 20696 Feed Regulating Screw.................
131240 20702 " Rocking Frame with two 453AL......
131732 " " " 131240 with 59343,
131197 and 131731.................
57234 20702 Feed Rocking Frame Hinge Pin..........
57235 20702
" " n « • gugjjlng (2)
453AL 20702
" • . » • «
Screw (2).........................
453AL 20702 Feed Rocking Frame Hinge Pin Set Screw
(2)...............................
25618 20704 Guide................. ...............
51224W 20704 " Thumb Screw.......................
131133 20707 Looper................................
13113 20707 “ 131133 with 229J and 131135......
54027 20698 " Carrier with two 175E............
175E 20698 " " Adjusting Screw (2)............
54227 20698 " " Connection.....................
54228 20698 " " “ Shaft........................
128419 20698 " " " "on Pad
(braided cotton)..................
68478 20698 Looper Carrier Connection Shaft Sleeve
(eccentric).......................
51263D 20698 Looper Carrier Connection Shaft Sleeve
Cap Screw.........................
68479 20698 Looper Carrier Driver with four 175E--
175E 20698 " " " Cap Screw (4).................
•68481 20698 " Driving Shaft and Feed Lifting Ec-
centric...........................
Note; When No. 68481 Is required for repairs, the
Arm Rotary Shaft must be returned to the factory
to be adjusted to the new part.
•68482 Looper Driving Shaft and Feed Lifting
Eccentric 68481 with 54027, 54227,
54228 and 68479...................
948J 20696 Looper Driving Shaft and Feed Lifting
Eccentric Bracket Screw...........
68484 20698 Looper Driving Shaft and Feed Lifting
Eccentric Bushing.................
131028 20698 Looper Driving Shaft and Feed Lifting
Eccentric Bushing Oil Plug........
