PARTS FOR MACHINE No. 147-80
No. Plate Name
131293 2069h
It
Rock Shaft.
131474
tl II It
131293 with 1235F, 127838
and 131475.
1309C 20695 Arm Rock Shaft Adjusting Screw........
131056 20695 "
II II
" " Washer...
68433 20695
N II II
Bushing (back).........
68435 20695
II II n
“ " Cap..............
131095 20695
M II H " n It Washer
(fibre)... .
446AL 20695 Arm Rock Shaft Bushing (back) Set Screw
68436 20695
II II
'' (Intel-mediate)...
423AL 20695
II n It
" “ Set
131343 20696 Arm Rock Shaft Crank, back (ball bearing,
solid) with two 50083AL..........
50083AL 20696 Arm Rook Shaft Crank (back) Set Screw
(2)......
131475 20695 Arm Rock Shaft Crank (front) with 853AL
127838 20695
II n If
" " Pin..............
131456 20695 '*
M H
Flanged Bushing (front)..
453AL 20695
II If If
" " " Set
42365 20695 Arm Rock Shaft Oil Pad (braided cotton)
for oiling Back Bearing...........
54969 20695 Arm Rock Shaft Oil Pad (braided cotton)
for oiling Intermediate Bearing...
1235F 20695 Arm Rook Shaft Oil Plug Screw.........
131476 20696
II
Rotary Shaft.....................
Note: When No. 131476 Is required for repairs, the
Looper Driving Shaft and Feed Lifting Eccentric
must be returned to the factory to be adjusted
to the new part.
131477 Arm
131366
131478
131479
20696
20696
Arm
It
If
131526 Arm
131369 20696 Arm
205C 20696 Arm
131370 20696 Arm
429C 20696 Arm
131484 and 131502.
II II II II n Qggg
t| II II n n II
131478 With 131369 and three 205C...
Rotary Shaft Ball Bearing (back)
Case with Ball Bearings complete,
Nos. 131479, 131480 and two 131366..
Case Cap.
Case Cap Screw (3)...
Rotary Shaft Ball Bearl
Case Position Stud (3).
Rotary Shaft Ball Bearl
Case Set Screw.......
PARTS FOR MACHINE No. 147-80
No. Plate Name
131480 20696 Arm Rotary Shaft Ball Bearing (back)
Spacing Collar....................
131366 20696 Arm Rotary Shaft Ball Bearing (Inter­
mediate) .........................
131481 20696 Arm Rotary Shaft Ball Bearing (inter­
mediate) Case.....................
1304C 20696 Arm Rotary Shaft Ball Bearing (Inter­
mediate) Case Set Screw...........
131482 20696 Arm Rotary Shaft Ball Bearing (Inter­
mediate) Collar with two 457AL....
457AL 20696 Arm Rotary Shaft Ball Bearing (Inter­
mediate) Collar Set Screw (2).....
131457 20696 Arm Rotary Shaft Bushing (front)......
76 IE 20696 " " " “ " Set Screw
42367 20696 " " " Front Bearing Oil Pad,
lower (braided cotton)............
54218 20696 Arm Rotary Shaft Front Bearing Oil Pad,
upper (braided cotton)............
144D 20696 Arm Rotary Shaft Screw................
131276 20688 " Side Cover (oil vent)..............
131277 20688 " " " Cap...........................
131280 20688 " " " " Position Pin................
51224W 20688 " " " " Thumb Screw.................
131278 20688 Arm Side Cover (oil vent) complete. Nos.
51224W, 131276, 131277 and 131280...
68448 20688 Arm Side Cover Gasket (vlctorlte).....
1057AL 20688 " “ " Screw (4).....................
131483 20696 Balance Wheel, 2 In. pulley, with two
51283AL, for round belt...........
131710 Balance Wheel "v" belt groove, with two
51283AL...........................
128510 20696 Balance Wheel Cover...................
51283AL 20696 " " Set Screw (2)..................
131374 20704 Cloth Plate...........................
68368 20704 " ” Slide (left)....................
131050 20704 " " " ” Spring.....................
725J 20704 " " « « " Screw (2)
131051 20704 Cloth Plate Slide (left) complete. Nos.
68368, 131050 and two 725J........
131375 20704 Cloth Plate Slide (right).............
131381 20704 " " " " Spring......................
725J 20704 " " “ " " Screw (2)
131382 20704 Cloth Plate Slide (right) complete. Nos.
131375, 131381 and two 725J.......
131380 20704 Cloth Plate complete, for Throat Plate
No. 38486, Nos. 131051, 131374 and
131382............................
lOllF 20704 Cloth Plate Screw (left) (2)..........
