Instructions For Using
S P A R T A N * SEWING MACHINE 192
Needles and Thread—
Use needles 15 x 1, in sizes 11, 14, 16 and 18.
You will obtain the best stitching results from
your sewing machine if it is fitted with a
SINGER needle.
Thread should be selected according to the
fabric to be stitched. Needle must be of correct
size for thread to pass freely through eye
of needle.
To Set the Needle—
Raise needle bar to its highest position.
Loosen needle clamp thumb screw and
insert needle
(flat side to the right)
up into
needle clamp as far as it will go.
Tighten needle clamp screw.
Fig. 1. To Set the Needle
To Thread the Needle—
Fig.
2.
Upper Threading
Raise take up lever 5 to highest point.
Place spool of thread on spool pin.
Lead thread into thread guide 1,
—Uown ?nd
from
ricrht !<^ft lv»fwee*i
♦ *
^
-
tension discs 2.
—Into loop of thread take-up spring 3
—Under slack thread regulator
4 (not
through eye in thread regulator)
—Up and from right to left through hole
in take-up lever 5
—Down through guide
6
on face plate
—Down through lower wire guide 7.
Thread from left to right through eye of
needle 8.
Draw about two inches of thread through
eye of needle with which to begin sewing.
To Remove The Bobbin—
Raise needle to its highest point.
Open slide plate.
Press bobbin ejector
J
and lift
out bobbin.
Fig.
3.
Removing the Bobbin
THE*SII^ER MANUFACTURING COMPANY
*A Trademark of THE SINGER MANUFACTURING COMPANY
Printed in Great Britain.-^
