Controls at a Glance......................
Electronic Clock and Oven Control (select models)
BA KE
BRO IL
V
• T
• /
7
.
/ ,
D C
J D
BAKE BROIL
>__________ >
CLOCK
©
TIMER
W
* ___________
NOTE: The display will flash when the appliance is first connected to power or if power is interrupted. The display
will stop flashing once the time-of-day clock has been set. The BAKE, BROIL and TIMER indicators light when the
function pad is pressed.
CANCEL Pad
Press this pad to cancel all operations except the clock and
timer.
▲ and ▼ Pads
Press and tap, or press and hold, these pads to enter the de­
sired time, temperature, or to select HI or LO broil.
BAKE Pad
Use for baking or roasting.
1. Press BAKE pad.
2. Press A or ▼ pad to set the oven temperature.
See page 9 for additional information.
BROIL Pad
Use for top browning and broiling.
1. Press BROIL pad.
2. Press A or T pad for HI or LO broil.
See page 12 for additional information.
Setting the Clock
1. If the display is flashing, press the CLOCK pad to stop the
flashing, then press the CLOCK pad again.
• If the colon is not flashing, press the CLOCK pad.
• The clock time cannot be set if the control is programmed
for a bake, broil or timing operation.
2. Set the correct time of day using the A and ▼ pads. If the A
or T pad is not pressed within 30 seconds, the program will
cancel. Press the CLOCK pad and begin again.
Setting the Timer
The timer can be set from one minute (:01) up to 9 hours
and 50 minutes (9:50). Time will be displayed in minutes
and not in seconds. THE TIMER DOES NOT CONTROL
THE OVEN.
1. Press the TIMER pad.
• :00 and the TIMER indicator light will appear in the
display. The colon will flash.
2. Press the A or T pad until the desired time is displayed.
• The timer will begin as soon as the time is set.
• The flashing colon indicates that a timing operation
is in progress. The colon will not flash if the time of
day or oven temperature is displayed.
• The timer countdown will be displayed unless an­
other function is programmed after setting the timer.
• A single beep signals the end of the operation.
“END” will appear in the display. If the time of day
or oven temperature is displayed “END” will not
appear.
• A short beep will sound every 30 seconds for five
minutes to remind you that the operation has completed.
3. If desired, press the TIMER pad and the time of day
will reappear in the display during a timing operation.
To cancel the timer operation: Press and hold the
TIMER pad for three seconds.
Additional Information
• A beep will sound each time a function pad is pressed.
There is no beep for the A or T pad.
• If a fault code (example: F2) is displayed and beeps
sound, press the CANCEL pad. If the fault code contin­
ues, see page 17.
