PART N0. DESCRIPTION PART HU. DESCRIPTION
1 544262-101 Presser Regulating Thum Screw 39 370243 Needle Bar Crank Rod Comp.
2 410355 Presser Bar Spring
3 544204-001 Presser Bar Guide Bracket Screw
4 410352 Presser Bar Guide Bracket Comp. 42 511030 Needle Bar Crank Rod Slide Block
5 412787-100 Presser Bar Lifter 43 543301-006 Needle Bar Crank Rod Slide Block Pin Retaining
Г) 544441 Presser Bar Lifter Screw Stud 44 370242 Needle Bar Crank Rod Comp.
7 410351 Presser Bar 45 410461 Needle Bar Eccentric Саш Comp.
8 504063-451 Presser F(юt Screw 46 544204-002 Needle Bar Eccentric Cam Set Screw(2)
9 376811 Presser Foot Comp. 47 410340 Needle Bar Crank Rod Pin
48 54,3801-006 Needle Bar Crank Rod Pin Retaining Ring
11 410348 Presser Foot Spring 49 410463 Needle Thread Take-up
12 376845 Needle Clamp 50 54421 1-0,51Needle Thread Take-up Screw
13 374102 Needle Bar Set Screw 51 410451 Needle Bar Connecting Link Comp.
14 376805 Needle Set Screw
15 544211-059 Needle Bar Thread Guide Set Screw
16 410322-100 Needle Bar Bushing (upper) Cap
17 410323
Needle Bar Bushing (upper)
19 376844 Needle Bar
21 376846 Needle Bar Thread Guide
23 410324 Needle Bar Bushing (lower)
24 N2054-01-14 Needle (ltl4)
25
376814 Arm Shaft
26 544204-002 Arm Shaft Set Screw(2)
28 543801-007 Arm Shaft Retaining Ring
30 410325 Needle Bar Connecting Stud
31 544044 Needle Bar Connecting Stud Screw
32 410340 Needle Bar Connecting Link Pin
33 543801-006 Needle Bar Connecting Link Pin Retaining Ring
34 410327 Needle Bar Connecting Link
35 412707-001 Needle Bar Crank Comp
36 544203-001 Needle Bar Crank Rod Pin Screw
38 544203-001 Needle Bar Connecting Link Pin
