SINGER 14U32A - Manual (Page 17)

7
PART HO. DESCRIPTION 1 PART N0.
10 4.19375ji00.1. Motor CoBp.Jfor UL'CSA) ' i 1'13'/UT7J
1
I
12 544259 Motor Bracket Clamping Screw
13 543805-005 Motor Bracket Clamping Screw 'Jasher
14 410252 Rotating Shaft Bushing (left)
17 410470 Rotating Shaft Collar Comp.
18 544204-001 Rotating Shaft Collar Set Screw (2)
19 408730 Rotating Shaft Thrust Washer(2)
20 410253 Rotating Shaft Bushing (right)
22 376816 Rotating Shaft
23 543801-010 Rotating Shaft Retaining Ring
25 543809-004 Rotating Shaft Spring Pin
26 376808 Rotating Shaft Comp.
27 410268-002 Pu' ley
28 543848 Pulley Set Screw Washer
29 544270-001 Pul ley Set Screw
30 412721 Motor Belt
31. 419115-002 Control le_r Comp. (for DL/CSA) U o j '"i It 1 \ ‘ j L ( J ' i
32 419376-901 Electrical Data Plate (for IJL/CSA)
32 419376-904 Electrical Data Plate (for UL)
Di^SCRIPTION
