30 PARTS FOR MACHINE No, 147-37
No. Plate Name
54061 9883 Looper Holder with 1120C and 1147C........................
704W 8958 Screw................................................
64319 9397 Needle Bar (hollow)...................................................
131045 20693 Needle Bar complete, for 3/16 In. to 3/8
In. gauges, Nos. 64319 and 131044...
Note: When ordering No. 131045, state gauge required.
Needle Bar Bushing (lower).............................................
" " " " Set Screw....
" " " (upper)..............................................
" " " " Set Screw______
" “ Connecting Link..........................................
" " " " 54326 with
54327 and 54328.....................................................
Needle Bar Connecting Link Hinge Stud...
" " “ " '' " Nut
" " " Stud with 211F and
two 187E.................................................................
Needle Bar Connecting Stud Clamping
Screw.......................................................................
Needle Clamp with two 1498F, for 3/16 In.
to 3/8 In. gauges......................................................
ordering No. 131044, state gauge required.
Needle Guard, for 3/16 In. to 3/8 In.
gauges......................................................................
Needle Guard Clamp........................................................
" Set Screw................................................................
Oil Tube............................................................................
" " Bracket...............................................................
“ Packing (felt).....................................................
Oil Tube complete, for oiling Crank Con­
necting Rod (upper bearing). Nos.
49092, 54108 and 54109.........................................
Pressure Regulating Thumb Screw..................................
" ” " " Lock Nut
Slack Thread Controller...................................................
" " " Clamp....................................
" " " " Screw.................
" " Regulator.....................................................
" " " Holder with 175E
and two 50150C.......................................................
Slack Thread Regulator Holder Clamping
Screw.......................................................................
Slack Thread Regulator Holder Shaft..............................
38456 9882
1133E 8958
68187 9898
1133E 8958
54326 9882
54329
54327 9882
1520J 9901
54328 9882
187E 8958
131044 20693
Note : Whe
68197 9898
68123 9897
1498F 8958
54108 —
54109 —
49092 9870
54110 9870
574W 8958
1539W 9901
54381 9870
54242 9870
190D 8958
68199 9899
54042 9870
175E 8958
64043 9870
24292 9870
1019C 8958
54044 9870
1253C 3958
Collar with 1019C..........................................
Slack Thread Regulator Holder Shaft
Collar Set Screw.............................................
Slack Thread Regulator Holder Shaft
Crank (forked) with 1253C............................
Slack Thread Regulator Holder Shaft
Crank Set Sci’ew............................................
PARTS FOR MACHINE No. 147-37 31
No. Plate Name
50150C 3958 Slack Thread Regulator Set Screw.............................................
2102 3964 Tension (under thread) Disc.......................................................
51570G 8964 " '' '' Regulating Thumb
Nut............................................................................
50326C 8964 Tension (under thread) Screw Stud............................................
^9539 -------- " ................................................ 50326C
with 51570C.............................................................
59534 8964 Tension (under thread) Spring............................
59537 8964 " " " ” Bushing
(large).......................................................................
59538 0964 Tension (under thread) Spring Bushing
(small).......................................................................
17547 8964 Tension (under thread) Thread Guide.............
54070 8996 " (upper thread) Bracket...........................
376D 8958 " n .1 « Screw__
2102 8964 ” “ " Disc.............................
61570C 8964 " “ “ Regulating Thumb
Nut.............................................................................
32572 8964 Tension (upper thread) Releasing Disc...
54988 8964 " " " " Pin_____
54071 9889 " “ " " Shaft..
54047 8964 " “ " " "
Crank with 624C.......................................................
54048 8964 Tension (upper thread) Releasing Shaft
Crank Link................................................................
624C 8956 Tension (upper thread) Releasing Shaft
Crank Set Screw.......................................................
66261 9901 Tension (upper thread) Releasing Shaft
Spring........................................................................
316F 3958 Tension (upper thread) Releasing Shaft
Stop Screw................................................................
1547J 9901 Tension (upper thread) Releasing Shaft
Stop Screw Nut.........................................................
50326C 8964 Tension (upper thread) Strew Stud.....................
59539 -------- " H « n II 50326C
with 51570C..............................................................
59535 8964 Tension (upper thread) Spring.............................
59537 8964 " " " " Bushing
(large).......................................................................
59538 8964 Tension (upper thread) Spring Bushing
(small)......................................................................
131696 20693 Tension (upper thread) Thread Guide
(double)....................................................................
53225 9899 Thread (under) Eyelet (back)...................................
lOOD 8958 " '' " " Screw....................
54072 9898 " " " (front)....................................
64351 9370 " " Nipper Cam with 465C................
4G5C 3958 " " " " Set Screw......................
33210 9370 " '' " Spring (lower)____________
38211 9070 " " " " (upper)_________
